307-016 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 32POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Rows [custom] | Number of Positions/Bay/Row | Mounting Type | Gender | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Finish | Termination | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Color | Card Type | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Number of Rows | Features | Termination Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | 16 | Right Angle Through Hole | Female | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Tin | Solder | Copper Alloy | -40 C | 105 ░C | Dual | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | 3.96 mm | 0.156 in | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 16 | Through Hole | Female | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Wire Wrap | Copper Alloy | -40 C | 105 ░C | Single | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 16 | 1 | Card Guides | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 16 | Through Hole | Female | 4-40 Flush Mount Threaded Insert Top Opening | Tin | Solder | Copper Alloy | -40 C | 105 ░C | Single | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Single Edge | 3.96 mm | 0.156 in | 16 | 1 | Card Guides | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 16 | Right Angle Through Hole | Female | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Tin | Solder | Copper Alloy | -40 C | 105 ░C | Single | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Single Edge | 3.96 mm | 0.156 in | 16 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 8 | Through Hole | Female | Gold | Solder | Copper Alloy | -40 C | 105 ░C | Dual | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 16 | 2 | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | 16 | Surface Mount | Female | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Solder Eyelet(s) | Copper Alloy | -40 C | 105 ░C | Dual | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 16 | Through Hole | Female | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Solder | Copper Alloy | -40 C | 105 ░C | Single | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 16 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 8 | Through Hole | Female | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | Gold | Wire Wrap | Copper Alloy | -40 C | 105 ░C | Dual | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 16 | 2 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 16 | Through Hole | Female | Flush Mount M3 Threaded Insert Top Opening | Gold | Wire Wrap | Copper Alloy | -40 C | 105 ░C | Single | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Single Edge | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | 16 | 1 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 2 | 16 | Right Angle Through Hole | Female | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Gold | Solder | Copper Alloy | -40 C | 105 ░C | Dual | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Green | Non Specified - Dual Edge | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin |
