316-036 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, SINGLE SIDE, 1.57 MM, 36 CONTACTS, THROUGH HOLE MOUNT, STRAIGHT
| Part | Termination Rows | Material - Insulation | Termination | Number of Positions | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Number of Rows [custom] | Pitch | Pitch | Color | Flange Feature | Number of Positions/Bay/Row | Contact Material | Card Type | Read Out | Gender | Contact Finish | Mounting Type | Contact Type | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 72 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 3.96 mm | 0.156 in | Green | Flush Mount M3 Threaded Insert Top Opening | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | Female | Tin | Panel Mount Through Hole | Cantilever | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 72 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 3.96 mm | 0.156 in | Green | Flush Mount Side Opening Unthreaded | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | Female | Tin | Panel Mount Through Hole | Cantilever | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 72 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 3.96 mm | 0.156 in | Green | Flush Mount Top Opening Unthreaded | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | Female | Tin | Panel Mount Through Hole | Cantilever | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 72 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 3.96 mm | 0.156 in | Green | Flush Mount M3 Threaded Insert Top Opening | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | Female | Tin | Panel Mount Through Hole | Cantilever | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 36 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 3.96 mm | 0.156 in | Green | 4-40 Flush Mount Threaded Insert Top Opening | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | Female | Gold | Through Hole | Cantilever | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder Eyelet(s) | 72 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 3.96 mm | 0.156 in | Green | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | Female | Tin | Free Hanging (In-Line) | Cantilever | ||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder Eyelet(s) | 72 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 3.96 mm | 0.156 in | Green | 4-40 Flush Mount Threaded Insert Top Opening | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | Female | Gold | Panel Mount | Cantilever | 0.25 Ám | 10 Áin | Card Guides | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder Eyelet(s) | 72 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 3.96 mm | 0.156 in | Green | 4-40 Flush Mount Threaded Insert Top Opening | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | Female | Tin | Panel Mount | Cantilever | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder | 72 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 3.96 mm | 0.156 in | Green | Floating Bobbin Flush Mount | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | Female | Gold | Panel Mount Through Hole | Cantilever | 0.116 " | 2.95 mm | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Solder Eyelet(s) | 72 | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 3.96 mm | 0.156 in | Green | 4-40 Flush Mount Threaded Insert Top Opening | 36 | Copper Alloy | Non Specified - Dual Edge | Dual | Female | Tin | Panel Mount | Cantilever | Card Guides |
