845-065 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 65POS 0.100
| Part | Pitch | Pitch | Mounting Type | Card Thickness [Max] | Card Thickness [Min] | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Color | Termination Rows | Read Out | Gender | Number of Positions/Bay/Row | Card Type | Contact Material | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Number of Rows | Material - Insulation | Contact Type | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 0.1 " | 2.54 mm | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Green | 1 | Single | Female | 65 | Non Specified - Single Edge | Copper Alloy | Wire Wrap | 125 °C | -40 C | Gold | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.25 Ám | 10 Áin |
 EDAC Inc. | 0.1 " | 2.54 mm | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Green | 1 | Single | Female | 65 | Non Specified - Single Edge | Copper Alloy | Solder Eyelet(s) | 125 °C | -40 C | Gold | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.25 Ám | 10 Áin |
 EDAC Inc. | 0.1 " | 2.54 mm | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | 0.156 " | 3.96 mm | Green | 1 | Single | Female | 65 | Non Specified - Single Edge | Copper Alloy | Solder | 125 °C | -40 C | Gold | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 0.1 " | 2.54 mm | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | 4-40 Flush Mount Threaded Insert Top Opening | Green | 1 | Single | Female | 65 | Non Specified - Single Edge | Copper Alloy | Wire Wrap | 125 °C | -40 C | Gold | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 0.1 " | 2.54 mm | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | 4-40 Flush Mount Threaded Insert Top Opening | Green | 1 | Single | Female | 65 | Non Specified - Single Edge | Copper Alloy | Solder | 125 °C | -40 C | Gold | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 0.1 " | 2.54 mm | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Green | 1 | Single | Female | 65 | Non Specified - Single Edge | Copper Alloy | Solder | 125 °C | -40 C | Gold | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.25 Ám | 10 Áin |
 EDAC Inc. | 0.1 " | 2.54 mm | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Green | 1 | Single | Female | 65 | Non Specified - Single Edge | Copper Alloy | Wire Wrap | 125 °C | -40 C | Gold | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.25 Ám | 10 Áin |
 EDAC Inc. | 0.1 " | 2.54 mm | Right Angle Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Flush Mount M3 Threaded Insert Top Opening | Green | 1 | Single | Female | 65 | Non Specified - Single Edge | Copper Alloy | Solder | 125 °C | -40 C | Gold | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 0.1 " | 2.54 mm | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Flush Mount M3 Threaded Insert Top Opening | Green | 1 | Single | Female | 65 | Non Specified - Single Edge | Copper Alloy | Wire Wrap | 125 °C | -40 C | Gold | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 0.1 " | 2.54 mm | Through Hole | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 65 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Green | 1 | Single | Female | 65 | Non Specified - Single Edge | Copper Alloy | Solder Eyelet(s) | 125 °C | -40 C | Gold | 1 | Diallyl Phthalate (DAP) | Cantilever | 0.25 Ám | 10 Áin |
