1X03G00SB Series
Manufacturer: Oupiin
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
PIN HEADER, SINGLE ROW 3 PIN STR
| Part | Number of Positions Loaded | Current Rating | Number of Positions | Mounting Type | Contact Material | Insulation Height | Number of Rows | Material Flammability Rating | Pitch - Mating | Contact Type | Style | Insulation Color | Contact Finish - Post | Connector Type | Termination | Shrouding | Operating Temperature (Min) | Operating Temperature (Max) | Contact Shape | Contact Length - Mating | Contact Finish - Mating | Insulation Material | Contact Finish Thickness - Mating | Contact Length - Post | Fastening Type | Overall Contact Length | Contact Finish Thickness - Post | Contact Finish Thickness - Post (string_set) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Oupiin | All | 3 A | 3 | Through Hole | Brass | 0.098 in | 1 | UL94 V-0 | 0.1 in | Male Pin | Board | Black | Gold | Cuttable Header | Solder | Unshrouded | -40 °C | 105 °C | Square | 0.24 in | Gold | Polybutylene Terephthalate (PBT) | Flash | 0.118 in | Push-Pull | 0.457 in | Flash | Flash |
