2013519 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER R/A 10POS 7.5MM
| Part | Mounting Type | Insulation Color | Material Flammability Rating | Fastening Type | Contact Finish - Mating | Insulation Material | Contact Length - Post [x] | Contact Length - Post [x] | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions Loaded | Applications | Number of Positions | Contact Shape | Termination | Shrouding | Contact Finish - Post | Number of Rows | Contact Type | Voltage Rating | Pitch - Mating | Pitch - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Connector Type | Style | Insulation Height | Insulation Height | Number of Positions Loaded |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Through Hole Right Angle | Black | UL94 V-0 | Detent Lock | Gold | Glass Filled Polyester Thermoplastic | 0.15 in | 3.81 mm | Copper Alloy | -30 ░C | 105 ░C | 7 | General Purpose Industrial | 10 | Rectangular | Solder | Shrouded - 4 Wall | Tin | 1 | Tab | 300 VDC | 7.5 mm | 0.295 in | 15 µin | 0.38 µm | Header | Board to Board Cable | 13 mm | 0.512 in | |
 TE Connectivity Raychem Cable Protection | Through Hole Right Angle | Black | UL94 V-0 | Detent Lock | Gold | Glass Filled Polyester Thermoplastic | 0.15 in | 3.81 mm | Copper Alloy | -30 ░C | 105 ░C | General Purpose Industrial | Rectangular | Solder | Shrouded - 4 Wall | Tin | 1 | Tab | 300 VDC | 7.5 mm | 0.295 in | 15 µin | 0.38 µm | Header | Board to Board Cable | 13 mm | 0.512 in | All |
