396-012 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 12POS 0.125
| Part | Material - Insulation | Termination Rows [custom] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Gender | Pitch | Pitch | Color | Contact Finish | Termination | Number of Rows [custom] | Contact Material | Contact Type | Card Type | Mounting Type | Number of Positions | Number of Positions/Bay/Row | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Read Out | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Female | 3.18 mm | 0.125 in | Black | Gold | Solder | 2 | Copper Alloy | Cantilever | Non Specified - Dual Edge | Through Hole | 12 | 6 | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | |||
 EDAC Inc. | Polyester Thermoplastic | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm | Female | 3.18 mm | 0.125 in | Black | Gold | Solder | Copper Alloy | Cantilever | Non Specified - Single Edge | Through Hole | 12 | 12 | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 4-40 Flush Mount Threaded Insert Top Opening | Female | 3.18 mm | 0.125 in | Black | Gold | Solder Wire Wrap | Copper Alloy | Cantilever | Non Specified - Single Edge | Right Angle Through Hole | 12 | 12 | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | 1 | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 0.128 " | 3.25 mm | Female | 3.18 mm | 0.125 in | Black | Gold | Wire Wrap | Copper Alloy | Cantilever | Non Specified - Single Edge | Through Hole | 12 | 12 | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | 2 | M3 Threaded Insert Top Mount Opening | Female | 3.18 mm | 0.125 in | Black | Gold | Solder | 2 | Copper Alloy | Cantilever | Non Specified - Dual Edge | Through Hole | 12 | 6 | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | Flush Mount M3 Threaded Insert Top Opening | Female | 3.18 mm | 0.125 in | Black | Gold | Solder Wire Wrap | 2 | Copper Alloy | Cantilever | Non Specified - Dual Edge | Right Angle Through Hole | 12 | 6 | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | |||||
 EDAC Inc. | Polyester Thermoplastic | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Female | 3.18 mm | 0.125 in | Black | Gold | Solder Wire Wrap | Copper Alloy | Cantilever | Non Specified - Single Edge | Right Angle Through Hole | 12 | 12 | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm | Female | 3.18 mm | 0.125 in | Black | Gold | Solder | 2 | Copper Alloy | Cantilever | Non Specified - Dual Edge | Through Hole | 12 | 6 | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Female | 3.18 mm | 0.125 in | Black | Gold | Solder Wire Wrap | 2 | Copper Alloy | Cantilever | Non Specified - Dual Edge | Right Angle Through Hole | 12 | 6 | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 4-40 Threaded Insert Top Mount Opening | Female | 3.18 mm | 0.125 in | Black | Gold | Solder | 2 | Copper Alloy | Cantilever | Non Specified - Dual Edge | Through Hole | 12 | 6 | -40 C | 105 ░C | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | Card Guides |
