9046-9513 Series
Manufacturer: Radiall USA, Inc.
Beta
⌘K
SMA / STRAIGHT PLUG MALE PASSIVA
| Part | Mating Cycles | Body Material | Voltage Rating | Dielectric Material | Center Contact Plating | Operating Temperature [Min] | Operating Temperature [Max] | Contact Termination | Impedance | Frequency - Max [Max] | Number of Ports | Mounting Type | Connector Type | Mounting Feature | Connector Style | Shield Termination | Fastening Type | Housing Color | Center Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Radiall USA, Inc. | 500 | Stainless Steel | 335 V | Polytetrafluoroethylene (PTFE) | Gold | -65 ░C | 250 °C | Compression | 50 Ohms | 26 GHz | 1 | Panel Mount | Plug Male Pin | Flange | SMA | Screw | Threaded | Silver | Beryllium Copper |
Radiall USA, Inc. | 500 | Stainless Steel | 335 V | Polytetrafluoroethylene (PTFE) | Gold | -65 ░C | 165 °C | Compression | 50 Ohms | 26 GHz | 1 | Panel Mount | Plug Male Pin | Flange | SMA | Screw | Threaded | Silver | Beryllium Copper |
