Ｍold type, Yellow Chip LED
Description
AI
SML-H1 series is a mold surface-mount type chip LED.
Beta
⌘K
Ｍold type, Yellow Chip LED
Ｍold type, Yellow Chip LED
| Part | Wavelength - Dominant | Current - Test | Lens Style | Millicandela Rating | Size / Dimension [x] | Size / Dimension [y] | Voltage - Forward (Vf) (Typ) | Lens Transparency | Configuration | Color | Lens Color | Package / Case | Height (Max) [Max] [z] | Lens Size [x] | Lens Size [y] | Supplier Device Package | Supplier Device Package | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 590 nm | 20 mA | Rectangle with Flat Top | 63 mcd | 2 mm | 1.25 mm | 2.2 V | Clear | Standard | Yellow | Colorless | 0805 | 0.9 mm | 1.52 mm | 1.25 mm | 2012 | 0805 | Surface Mount |
