M2023TX Series

Catalog

SWITCH ROCKER DPDT 0.4VA 28V

Part	Mechanical Life	Electrical Life	Features	Mounting Type	Approval Agency	Termination Style	Circuit	Switch Function	Operating Temperature [Max]	Operating Temperature [Min]	Voltage Rating - DC	Actuator Marking	Current Rating (Amps)	Voltage Rating - AC	Actuator Type	Color - Actuator/Cap
NKK Switches M2023TXG45-DH	50000 Cycles	50000 Cycles	Epoxy Sealed Terminals	Right Angle Through Hole Vertical	CSA UL	PC Pin	DPDT	On-Off-On	85 °C	-30 ░C	28 V	No Marking	0.4 VA	28 V	Concave
NKK Switches M2023TXW13	50000 Cycles	25000 Steps	Epoxy Sealed Terminals	Through Hole	CSA UL	PC Pin	DPDT	On-Off-On	85 °C	-30 ░C	30 V	Varies by Cap	3 A 6 A	125 V	Actuator Arm Cap Required
NKK Switches M2023TXG45	50000 Cycles	50000 Cycles	Epoxy Sealed Terminals	Right Angle Through Hole Vertical	CSA UL	PC Pin	DPDT	On-Off-On	85 °C	-30 ░C	28 V	Varies by Cap	0.4 VA	28 V	Actuator Arm Cap Required
NKK Switches M2023TXW13-DA	50000 Cycles	25000 Steps	Epoxy Sealed Terminals	Through Hole	CSA UL	PC Pin	DPDT	On-Off-On	85 °C	-30 ░C	30 V	No Marking	3 A 6 A	125 V	Concave	Black
NKK Switches M2023TXW13-DC	50000 Cycles	25000 Steps	Epoxy Sealed Terminals	Through Hole	CSA UL	PC Pin	DPDT	On-Off-On	85 °C	-30 ░C	30 V	No Marking	3 A 6 A	125 V	Concave	Red
NKK Switches M2023TXG30	50000 Cycles	50000 Cycles	Epoxy Sealed Terminals	Right Angle Through Hole	CSA UL	PC Pin	DPDT	On-Off-On	85 °C	-30 ░C	28 V	Varies by Cap	0.4 VA	28 V	Actuator Arm Cap Required
NKK Switches M2023TXG30-FA	50000 Cycles	50000 Cycles	Epoxy Sealed Terminals	Right Angle Through Hole	CSA UL	PC Pin	DPDT	On-Off-On	85 °C	-30 ░C	28 V	No Marking	0.4 VA	28 V	Concave	Black
NKK Switches M2023TXG15	50000 Cycles	50000 Cycles	Epoxy Sealed Terminals	Through Hole	CSA UL	PC Pin	DPDT	On-Off-On	85 °C	-30 ░C	28 V	Varies by Cap	0.4 VA	28 V	Actuator Arm Cap Required
NKK Switches M2023TXW13-DB	50000 Cycles	25000 Steps	Epoxy Sealed Terminals	Through Hole	CSA UL	PC Pin	DPDT	On-Off-On	85 °C	-30 ░C	30 V	Varies by Cap	3 A 6 A	125 V	Actuator Arm Cap Required	White
NKK Switches M2023TXG41-DC	50000 Cycles	50000 Cycles	Epoxy Sealed Terminals	Right Angle Through Hole Vertical	CSA UL	PC Pin	DPDT	On-Off-On	85 °C	-30 ░C	28 V	No Marking	0.4 VA	28 V	Concave	Red
