392-007 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 7POS 0.100
| Part | Termination Rows | Material - Insulation | Contact Material | Mounting Type | Read Out | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish Thickness | Contact Finish Thickness | Gender | Operating Temperature [Min] | Operating Temperature [Max] | Card Thickness [Max] | Card Thickness [Min] | Termination | Number of Positions | Contact Type | Number of Positions/Bay/Row | Number of Rows | Card Type | Color | Contact Finish | Pitch | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Through Hole | Single | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 7 | Cantilever | 7 | 1 | Non Specified - Single Edge | Black | Gold | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Through Hole | Single | Flush Mount M3 Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 7 | Cantilever | 7 | 1 | Non Specified - Single Edge | Black | Gold | 0.1 " | 2.54 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Through Hole | Single | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 " | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 7 | Cantilever | 7 | 1 | Non Specified - Single Edge | Black | Gold | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Through Hole | Single | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 7 | Cantilever | 7 | 1 | Non Specified - Single Edge | Black | Gold | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Right Angle Through Hole | Single | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Wire Wrap | 7 | Cantilever | 7 | 1 | Non Specified - Single Edge | Black | Gold | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Through Hole | Single | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 7 | Cantilever | 7 | 1 | Non Specified - Single Edge | Black | Gold | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Through Hole | Single | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 7 | Cantilever | 7 | 1 | Non Specified - Single Edge | Black | Gold | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Through Hole | Single | 4-40 Flush Mount Threaded Insert Top Opening | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Wire Wrap | 7 | Cantilever | 7 | 1 | Non Specified - Single Edge | Black | Gold | 0.1 " | 2.54 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Through Hole | Single | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 7 | Cantilever | 7 | 1 | Non Specified - Single Edge | Black | Gold | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Polyester Thermoplastic | Copper Alloy | Through Hole | Single | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | 0.25 Ám | 10 Áin | Female | -40 C | 105 ░C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 7 | Cantilever | 7 | 1 | Non Specified - Single Edge | Black | Gold | 0.1 " | 2.54 mm |
