5024C Series
Manufacturer: ALPHA WIRE
Beta
⌘K
MULTI-PAIR 8COND 22AWG BLK 1000'
| Part | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Conductor Insulation | Conductor Strand [custom] | Conductor Strand [custom] | Features | Operating Temperature [Min] | Operating Temperature [Max] | Conductor Material | Jacket Color | Jacket (Insulation) Material | Length | Length | Number of Conductors | Usage | Wire Gauge | Cable Type | Voltage | Ratings | Length [x] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | 0.813 mm | 0.032 in | 6.78 mm | 0.267 in | Poly-Vinyl Chloride (PVC) | 30 AWG | 7 | Biological Compatibility Rip Cord | -35 °C | 105 ░C | Copper Tinned | Black | Poly-Vinyl Chloride (PVC) | 304.8 m | 1000 ft | 8 | Communication Control | 22 AWG | Multi-Pair | 300 VDC | ISO 10993 UL Style 2464 | ||
 ALPHA WIRE | 0.813 mm | 0.032 in | 6.78 mm | 0.267 in | Poly-Vinyl Chloride (PVC) | 30 AWG | 7 | Biological Compatibility Rip Cord | -35 °C | 105 ░C | Copper Tinned | Slate | Poly-Vinyl Chloride (PVC) | 8 | Communication Control | 22 AWG | Multi-Pair | 300 VDC | ISO 10993 UL Style 2464 | 100 ft | 30.5 m | ||
ALPHA WIRE | 0.813 mm | 0.032 in | 6.78 mm | 0.267 in | Poly-Vinyl Chloride (PVC) | 30 AWG | 7 | Biological Compatibility Rip Cord | -35 °C | 105 ░C | Copper Tinned | Slate | Poly-Vinyl Chloride (PVC) | 8 | Communication Control | 22 AWG | Multi-Pair | 300 VDC | ISO 10993 UL Style 2464 |
