833-033 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 33POS 0.156
| Part | Material - Insulation | Termination Rows | Number of Positions [custom] | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Termination | Color | Contact Material | Number of Positions/Bay/Row | Contact Type | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Number of Rows | Card Thickness [Max] | Card Thickness [Min] | Gender |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 33 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Solder | Green | Copper Alloy | 33 | Cantilever | Through Hole | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Single | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 33 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Solder | Green | Copper Alloy | 33 | Cantilever | Right Angle Through Hole | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 4-40 Threaded Insert Top Mount Opening | Single | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 33 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Solder Eyelet(s) | Green | Copper Alloy | 33 | Cantilever | Through Hole | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 0.156 " | 3.96 mm | Single | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 33 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Solder | Green | Copper Alloy | 33 | Cantilever | Through Hole | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Single | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 33 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Wire Wrap | Green | Copper Alloy | 33 | Cantilever | Through Hole | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Single | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 33 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Solder | Green | Copper Alloy | 33 | Cantilever | Right Angle Through Hole | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Single | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 33 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Solder | Green | Copper Alloy | 33 | Cantilever | Through Hole | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Flush Mount M3 Threaded Insert Top Opening | Single | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 33 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Solder | Green | Copper Alloy | 33 | Cantilever | Right Angle Through Hole | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Single | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 33 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Solder | Green | Copper Alloy | 33 | Cantilever | Through Hole | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Single | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 33 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Solder | Green | Copper Alloy | 33 | Cantilever | Through Hole | 0.25 Ám | 10 Áin | 3.96 mm | 0.156 in | 4-40 Threaded Insert Top Mount Opening | Single | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female |
