TPS8268150 Series
Manufacturer: Texas Instruments
Beta
⌘K
1.6-A, HIGH-EFFICENCY MICROSIP™ STEP-DOWN CONVERTER MODULE
| Part | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Current - Output (Max) [Max] | Efficiency | Voltage - Output 1 | Applications | Voltage - Input (Max) [Max] | Features | Operating Temperature [Max] | Operating Temperature [Min] | Type | Number of Outputs | Mounting Type | Package / Case | Voltage - Input (Min) [Min] | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Texas Instruments | 2.9 mm | 0.09 " | 0.11 in | 0.04 in | 1 mm | 2.3 mm | 1.6 A | 90 % | 1.5 V | ITE (Commercial) | 5.5 V | OCP OTP Remote On/Off UVLO | 85 °C | -40 C | Non-Isolated PoL Module | 1 | Surface Mount | 9-SMD Module | 2.5 V | 9-USIP |
Texas Instruments | 2.9 mm | 0.09 " | 0.11 in | 0.04 in | 1 mm | 2.3 mm | 1.6 A | 90 % | 1.5 V | ITE (Commercial) | 5.5 V | OCP OTP Remote On/Off UVLO | 85 °C | -40 C | Non-Isolated PoL Module | 1 | Surface Mount | 9-SMD Module | 2.5 V | 9-USIP |
