Mini-Fit Max Vertical Header, Dual Row, Through Hole, 8 Circuits, Tin (Sn) Plating, Black, Glow-Wire Capable
Mini-Fit Max Vertical Header, Dual Row, Through Hole, 8 Circuits, Tin (Sn) Plating, Black, Glow-Wire Capable
Mini-Fit Max Vertical Header, Dual Row, Through Hole, 8 Circuits, Tin (Sn) Plating, Black, Glow-Wire Capable
| Part | Insulation Material | Insulation Color | Insulation Height | Insulation Height | Row Spacing - Mating | Row Spacing - Mating | Number of Positions | Connector Type | Material Flammability Rating | Contact Type | Current Rating (Amps) | Features | Mounting Type | Contact Length - Post | Contact Length - Post | Contact Material | Fastening Type | Shrouding | Contact Finish - Post | Termination | Voltage Rating | Style | Pitch - Mating | Pitch - Mating | Contact Shape | Number of Rows | Number of Positions Loaded | Operating Temperature [Min] | Operating Temperature [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Liquid Crystal Polymer (LCP) | Black | 13.6 mm | 0.535 in | 4.2 mm | 0.165 in | 8 | Header | UL94 V-0 | Male Pin | 20 A | Board Guide | Through Hole | 0.144 in | 3.66 mm | Copper Alloy | Locking Ramp | Shrouded - 4 Wall | Tin | Solder | 600 VAC | Board to Cable/Wire | 4.2 mm | 0.165 in | Square | 2 | All | -40 °C | 105 ░C |
