PTVS6 Series

Catalog

HIGH CURRENT BIDIRECTIONAL TVS DIODE /TRAY PACKAGING

Part	Capacitance @ Frequency	Current - Peak Pulse (10/1000µs)	Current - Peak Pulse (10/1000µs)	Voltage - Breakdown (Min) [Min]	Voltage - Clamping (Max) @ Ipp [Max]	Type	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Bidirectional Channels [custom]	Package / Case	Package / Case [custom]	Voltage - Reverse Standoff (Typ)	Applications	Supplier Device Package
Bourns Inc. PTVS6-430C-TH	700 pF	6 kA	6000 A	440 V	580 V	Zener	Through Hole	-55 ░C	125 °C	1	Axial Right Angle Bend	24.15 mm	430 V	General Purpose	Axial
Bourns Inc. PTVS6-066C-M	4100 pF	6 kA	6000 A	72 V	120 V	Zener	Surface Mount	-55 ░C	125 °C	1	2-SMD Flat Leads		66 V	General Purpose	2-SMD
Bourns Inc. PTVS6-076C	3300 pF	6 kA	6000 A	85 V	140 V	Zener	Through Hole	-55 °C	150 °C	1	Axial Right Angle Bend	24.15 mm	76 V	General Purpose	Axial
Bourns Inc. PTVS6-380C	650 pF	6 kA	6000 A	401 V	520 V	Zener	Through Hole	-55 °C	150 °C	1	Axial Right Angle Bend	24.15 mm	380 V	General Purpose	Axial
Bourns Inc. PTVS6-076C-SH	3300 pF	6 kA	6000 A	85 V	140 V	Zener	Surface Mount	-55 ░C	125 °C	1	2-SMD		76 V	General Purpose	2-SMD
Bourns Inc. PTVS6-430C	700 pF	6 kA	6000 A	440 V	580 V	Zener	Through Hole	-55 °C	150 °C	1	Axial Right Angle Bend	24.15 mm	430 V	General Purpose	Axial
Bourns Inc. PTVS6-076C-TH	3300 pF	6 kA	6000 A	85 V	140 V	Zener	Through Hole	-55 ░C	125 °C	1	Axial Right Angle Bend	24.15 mm	76 V	General Purpose	Axial
Bourns Inc. PTVS6-058C-SH	10 kHz 4500 pF	6 kA	6000 A	64 V	110 V	Zener	Surface Mount	-55 ░C	125 °C	1	2-SMD		58 V	General Purpose	2-SMD
Bourns Inc. PTVS6-076C-M	3300 pF	6 kA	6000 A	85 V	135 V	Zener	Surface Mount	-55 ░C	125 °C	1	2-SMD Flat Leads		76 V	General Purpose	2-SMD
