SG3225VAN Series

Manufacturer: EPSON

Catalog

SG3225VAN 156.250000M-KJBA0: XTA

Part	Current - Supply (Disable) (Max) [Max]	Base Resonator [custom]	Frequency	Current - Supply (Max) [Max]	Type	Output	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Frequency Stability	Mounting Type	Function	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Supply [Min]	Voltage - Supply [Max]	Supplier Device Package [x]	Supplier Device Package [y]	Supplier Device Package	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Package / Case
EPSON SG3225VAN 156.250000M-KJBA0	20 mA	Crystal	156.25 MHz	30 mA	XO (Standard)	LVDS	1.2 mm	0.047 "	50 ppm	Surface Mount	Enable/Disable	-20 ░C	70 °C	2.5 V	3.3 V	3.2	2.5	6-SMD	2.5 mm	0.098 in	3.2 mm	0.126 "	6-SMD No Lead
EPSON SG3225VAN 322.265625M-KJGA0	20 mA	Crystal	322.265625 MHz	30 mA	XO (Standard)	LVDS	1.2 mm	0.047 "	50 ppm	Surface Mount	Enable/Disable	-40 C	85 °C	2.5 V	3.3 V	3.2	2.5	6-SMD	2.5 mm	0.098 in	3.2 mm	0.126 "	6-SMD No Lead
EPSON SG3225VAN 148.351600M-KJGA0	20 mA	Crystal	148.3516 MHz	30 mA	XO (Standard)	LVDS	1.2 mm	0.047 "	50 ppm	Surface Mount	Enable/Disable	-40 C	85 °C	2.5 V	3.3 V	3.2	2.5	6-SMD	2.5 mm	0.098 in	3.2 mm	0.126 "	6-SMD No Lead
EPSON SG3225VAN 128.000000M-KJGA6	20 mA	Crystal	128 MHz	30 mA	XO (Standard)	LVDS	1.2 mm	0.047 "	50 ppm	Surface Mount	Enable/Disable	-40 C	85 °C	2.5 V	3.3 V	3.2	2.5	6-SMD	2.5 mm	0.098 in	3.2 mm	0.126 "	6-SMD No Lead
EPSON SG3225VAN 150.000000M-KEGA6	20 mA	Crystal	150 MHz	30 mA	XO (Standard)	LVDS	1.2 mm	0.047 "	30 ppm	Surface Mount	Enable/Disable	-40 C	85 °C	2.5 V	3.3 V	3.2	2.5	6-SMD	2.5 mm	0.098 in	3.2 mm	0.126 "	6-SMD No Lead
EPSON SG3225VAN 160.000000M-KJGAB	20 mA	Crystal	160 MHz	30 mA	XO (Standard)	LVDS	1.2 mm	0.047 "	50 ppm	Surface Mount	Enable/Disable	-40 C	85 °C	2.5 V	3.3 V	3.2	2.5	6-SMD	2.5 mm	0.098 in	3.2 mm	0.126 "	6-SMD No Lead
EPSON SG3225VAN 156.250000M-KJBA3	20 mA	Crystal	156.25 MHz	30 mA	XO (Standard)	LVDS	1.2 mm	0.047 "	50 ppm	Surface Mount	Enable/Disable	-20 ░C	70 °C	2.5 V	3.3 V	3.2	2.5	6-SMD	2.5 mm	0.098 in	3.2 mm	0.126 "	6-SMD No Lead
EPSON SG3225VAN 200.000000M-KJBA0	20 mA	Crystal	200 MHz	30 mA	XO (Standard)	LVDS	1.2 mm	0.047 "	50 ppm	Surface Mount	Enable/Disable	-20 ░C	70 °C	2.5 V	3.3 V	3.2	2.5	6-SMD	2.5 mm	0.098 in	3.2 mm	0.126 "	6-SMD No Lead
EPSON SG3225VAN 106.250000M-KEGA0	20 mA	Crystal	106.25 MHz	30 mA	XO (Standard)	LVDS	1.2 mm	0.047 "	30 ppm	Surface Mount	Enable/Disable	-40 C	85 °C	2.5 V	3.3 V	3.2	2.5	6-SMD	2.5 mm	0.098 in	3.2 mm	0.126 "	6-SMD No Lead
EPSON SG3225VAN 212.500000M-KEGAB		Crystal	212.5 MHz	30 mA	XO (Standard)	LVDS	1.2 mm	0.047 "	30 ppm	Surface Mount	Enable/Disable	-40 C	85 °C	2.5 V	3.3 V	3.2	2.5	6-SMD	2.5 mm	0.098 in	3.2 mm	0.126 "	6-SMD No Lead
