0603CS Series

Manufacturer: Delta Electronics/Components

Catalog

FIXED IND 220NH 250MA 1.6OHM SMD

Part	Shielding	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Inductance	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Current Rating (Amps)	Inductance Frequency - Test	DC Resistance (DCR)	Mounting Type	Q @ Freq	Tolerance	Frequency - Self Resonant	Type	Package / Case	Package / Case	Material - Core	Operating Temperature [Max]	Operating Temperature [Min]	Q @ Freq [custom]	Q @ Freq [custom]
Delta Electronics/Components 0603CS-221EKTS	Unshielded	1.02 mm	0.04 in	220 nH	0.046 in	1.16 mm	1.8 mm	0.071 "	0.25 A	100 MHz	1.6 Ohm	Surface Mount	25 100 MHz	10 %	1.2 GHz	Drum Core Wirewound	1608 Metric	0603	Ceramic	125 °C	-40 C
Delta Electronics/Components 0603CS-241EGTS	Unshielded	1.02 mm	0.04 in	240 nH	0.046 in	1.16 mm	1.8 mm	0.071 "	0.2 A	100 MHz	1.7 Ohm	Surface Mount	25 100 MHz	2 %	1.1 GHz	Drum Core Wirewound	1608 Metric	0603	Ceramic	125 °C	-40 C
Delta Electronics/Components 0603CS-301EGTS	Unshielded	1.02 mm	0.04 in	300 nH	0.046 in	1.16 mm	1.8 mm	0.071 "	150 mA	100 MHz	2.5 Ohm	Surface Mount	25 100 MHz	2 %	750 MHz	Drum Core Wirewound	1608 Metric	0603	Ceramic	125 °C	-40 C
Delta Electronics/Components 0603CS-4N3EGTS	Unshielded	1.02 mm	0.04 in	4.3 nH	0.046 in	1.16 mm	1.8 mm	0.071 "	700 mA	250 MHz	63 mOhm	Surface Mount	22 250 MHz	2 %	5.8 GHz	Drum Core Wirewound	1608 Metric	0603	Ceramic	125 °C	-40 C
Delta Electronics/Components 0603CS-101EJTS	Unshielded	1.02 mm	0.04 in	100 nH	0.046 in	1.16 mm	1.8 mm	0.071 "	400 mA	150 MHz	580 mOhm	Surface Mount	34 150 MHz	5 %	1.4 GHz	Drum Core Wirewound	1608 Metric	0603	Ceramic	125 °C	-40 C
Delta Electronics/Components 0603CS-111EJTS	Unshielded	1.02 mm	0.04 in	110 nH	0.046 in	1.16 mm	1.8 mm	0.071 "	0.3 A	150 MHz	610 mOhm	Surface Mount	32 150 MHz	5 %	1.35 GHz	Drum Core Wirewound	1608 Metric	0603	Ceramic	125 °C	-40 C
Delta Electronics/Components 0603CS-281EKTS	Unshielded	1.02 mm	0.04 in	0.28 µH	0.046 in	1.16 mm	1.8 mm	0.071 "	150 mA	100 MHz	2.4 Ohm	Surface Mount	25 100 MHz	10 %	1 GHz	Drum Core Wirewound	1608 Metric	0603	Ceramic	125 °C	-40 C
Delta Electronics/Components 0603CS-2N4EKTS	Unshielded	1.02 mm	0.04 in	2.4 nH	0.046 in	1.16 mm	1.8 mm	0.071 "	700 mA	250 MHz	140 mOhm	Surface Mount	15 250 MHz	10 %	4 GHz	Drum Core Wirewound	1608 Metric	0603	Ceramic	125 °C	-40 C
Delta Electronics/Components 0603CS-131EGTS	Unshielded	1.02 mm	0.04 in	130 nH	0.046 in	1.16 mm	1.8 mm	0.071 "	0.3 A	150 MHz	720 mOhm	Surface Mount	30	2 %	1.4 GHz	Drum Core Wirewound	1608 Metric	0603	Ceramic	125 °C	-40 C
Delta Electronics/Components 0603CS-1N6EKTS	Unshielded	1.02 mm	0.04 in	1.6 nH	0.046 in	1.16 mm	1.8 mm	0.071 "	700 mA	250 MHz	30 mOhm	Surface Mount		10 %	12.5 GHz	Drum Core Wirewound	1608 Metric	0603	Ceramic	125 °C	-40 C	250 MHz	24
