UDA133 Series
Manufacturer: NXP USA Inc.
Beta
⌘K
IC DAC/AUDIO 24BIT 100K 16SO
| Part | Type | Mounting Type | Operating Temperature (Min) | Operating Temperature (Max) | Voltage Supply Source | Sampling Rate (Per Second) | Package Name | Package Width | Package Length | Number of Channels | Resolution (Bits) | Data Interface | Voltage - Supply (Maximum) | Voltage - Supply (Minimum) | Voltage - Supply, Analog (Min) | Voltage - Supply, Analog (Max) | S/N Ratio (DACs) (Typical) | S/N Ratio (ADCs) (Typical) | Package / Case | Sigma Delta | Number of ADCs | Number of DACs | Voltage - Supply, Digital (Min) | Voltage - Supply, Digital (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NXP USA Inc. | Audio DAC | Surface Mount | -40 °C | 85 °C | Analog Digital | 100 kHz | 16-SO 16-SOIC | 3.9 mm | 0.154 in | 3 | 24 b | I2S | 3.6 V | 1.8 V | ||||||||||
 NXP USA Inc. | Audio DAC | Surface Mount | -40 °C | 85 °C | Analog Digital | 100 kHz | 16-LSSOP 16-SSOP | 4.4 mm | 0.173 in | 3 | 24 b | I2S | 3.6 V | 1.8 V | ||||||||||
NXP USA Inc. | Audio DAC | Surface Mount | -40 °C | 85 °C | Analog Digital | 100 kHz | 16-LSSOP 16-SSOP | 4.4 mm | 0.173 in | 3 | 24 b | I2S | 3.6 V | 1.8 V | ||||||||||
 NXP USA Inc. | Audio DAC | Surface Mount | -40 °C | 85 °C | Analog Digital | 96 kHz | 16-LSSOP 16-SSOP | 4.4 mm | 0.173 in | 2 | 24 b | I2S | 3.6 V | 2.4 V | ||||||||||
 NXP USA Inc. | Stereo Audio | Surface Mount | -20 °C | 85 °C | 44-PQFP | 10 mm | 10 mm | 24 b | Serial | 2.7 V | 3.6 V | 114 dB | 100 dB | 44-QFP | No | 5 | 6 | 2.7 V | 3.6 V | |||||
NXP USA Inc. | Audio DAC | Surface Mount | -40 °C | 85 °C | Analog Digital | 100 kHz | 16-LSSOP 16-SSOP | 4.4 mm | 0.173 in | 3 | 24 b | I2S | 3.6 V | 2.4 V | ||||||||||
NXP USA Inc. | Audio DAC | Surface Mount | -40 °C | 85 °C | Analog Digital | 100 kHz | 16-LSSOP 16-SSOP | 4.4 mm | 0.173 in | 2 | 24 b | I2S | 3.6 V | 1.8 V | ||||||||||
NXP USA Inc. | Audio DAC | Surface Mount | -40 °C | 85 °C | Analog Digital | 100 kHz | 16-SO 16-SOIC | 3.9 mm | 0.154 in | 3 | 24 b | I2S | 3.6 V | 1.8 V | ||||||||||
 NXP USA Inc. | Stereo Audio | Surface Mount | -20 °C | 85 °C | 44-PQFP | 10 mm | 10 mm | 24 b | Serial | 2.7 V | 3.6 V | 114 dB | 100 dB | 44-QFP | No | 5 | 6 | 2.7 V | 3.6 V | |||||
NXP USA Inc. | Audio DAC | Surface Mount | -40 °C | 85 °C | Analog Digital | 100 kHz | 16-LSSOP 16-SSOP | 4.4 mm | 0.173 in | 3 | 24 b | I2S | 3.6 V | 1.8 V |
