AST125 Series
Manufacturer: METZ CONNECT USA Inc.
Beta
⌘K
TERM BLK 11POS TOP ENTRY 5MM PCB
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Clamp Material - Plating | Contact Material - Plating | Number of Levels | Wire Termination | Mating Orientation | Wire Gauge [Min] | Wire Gauge [Max] | Current | Features | Pitch | Pitch | Voltage | Positions Per Level | Color | Mounting Type | Positions Per Level [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 METZ CONNECT USA Inc. | -40 C | 105 ░C | Steel | Copper Alloy - Tin Plated | 2 | Screwless - Spring Cage Tension Clamp | Vertical with Board | 12 AWG | 28 AWG | 15 A | Push Button Actuated | 0.197 in | 5 mm | 300 VDC | 11 | Gray | Through Hole | |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Steel | Copper Alloy - Tin Plated | 2 | Screwless - Spring Cage Tension Clamp | Vertical with Board | 12 AWG | 28 AWG | 15 A | Push Button Actuated | 0.197 in | 5 mm | 300 VDC | 3 | Gray | Through Hole | |
 METZ CONNECT USA Inc. | -40 C | 105 ░C | Steel | Copper Alloy - Tin Plated | 2 | Screwless - Spring Cage Tension Clamp | Vertical with Board | 12 AWG | 28 AWG | 15 A | Push Button Actuated | 0.197 in | 5 mm | 300 VDC | 4 | Gray | Through Hole | |
 METZ CONNECT USA Inc. | -40 C | 105 ░C | Steel | Copper Alloy - Tin Plated | 2 | Screwless - Spring Cage Tension Clamp | Vertical with Board | 12 AWG | 28 AWG | 15 A | Push Button Actuated | 0.197 in | 5 mm | 300 VDC | 6 | Gray | Through Hole | |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Steel | Copper Alloy - Tin Plated | 2 | Screwless - Spring Cage Tension Clamp | Vertical with Board | 12 AWG | 28 AWG | 15 A | Push Button Actuated | 0.197 in | 5 mm | 300 VDC | 20 | Gray | Through Hole | |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Steel | Copper Alloy - Tin Plated | 2 | Screwless - Spring Cage Tension Clamp | Vertical with Board | 12 AWG | 28 AWG | 15 A | Push Button Actuated | 0.197 in | 5 mm | 300 VDC | Gray | Through Hole | 7 | |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Steel | Copper Alloy - Tin Plated | 2 | Screwless - Spring Cage Tension Clamp | Vertical with Board | 12 AWG | 28 AWG | 15 A | Push Button Actuated | 0.197 in | 5 mm | 300 VDC | 12 | Gray | Through Hole | |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Steel | Copper Alloy - Tin Plated | 2 | Screwless - Spring Cage Tension Clamp | Vertical with Board | 12 AWG | 28 AWG | 15 A | Push Button Actuated | 0.197 in | 5 mm | 300 VDC | 8 | Gray | Through Hole | |
 METZ CONNECT USA Inc. | -40 C | 105 ░C | Steel | Copper Alloy - Tin Plated | 2 | Screwless - Spring Cage Tension Clamp | Vertical with Board | 12 AWG | 28 AWG | 15 A | Push Button Actuated | 0.197 in | 5 mm | 300 VDC | 2 | Gray | Through Hole | |
METZ CONNECT USA Inc. | -40 C | 105 ░C | Steel | Copper Alloy - Tin Plated | 2 | Screwless - Spring Cage Tension Clamp | Vertical with Board | 12 AWG | 28 AWG | 15 A | Push Button Actuated | 0.197 in | 5 mm | 300 VDC | 5 | Gray | Through Hole |
