Q20N Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
WORLD-BEAM Q20 SERIES: POLARIZED RETRO
| Part | Ingress Protection | Cable Length | Cable Length | Adjustment Type | Sensing Method | Operating Temperature [Min] | Operating Temperature [Max] | Sensing Distance | Sensing Distance | Voltage - Supply [Min] | Voltage - Supply [Max] | Output Configuration | Light Source | Connection Method | Response Time | Light Source |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | 78.74 " | 2 m | Adjustable Potentiometer | Polarized Retroreflective | -20 ░C | 60 °C | 13.12 ' | 4 m | 10 VDC | 30 VDC | NPN - Dark-ON/Light-ON | Red (645nm) | Cable | 800 µs | |
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Adjustable Potentiometer | Diffuse | -20 ░C | 60 °C | 10 VDC | 30 VDC | Red (655nm) | Connector | 800 µs | ||||||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Background Suppression | -20 ░C | 60 °C | 1.969 in | 5 cm | 10 VDC | 30 VDC | Red (655nm) | Connector | 800 µs | |||||
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Adjustable Potentiometer | Diffuse | -20 ░C | 60 °C | 31.496 in | 800 mm | 10 VDC | 30 VDC | Red (655nm) | Connector | 800 µs | ||||
 BANNER ENGINEERING | IP67 NEMA 6P | Adjustable Potentiometer | Background Suppression | -20 ░C | 60 °C | 7.874 in | 200 mm | 10 VDC | 30 VDC | NPN - Dark-ON/Light-ON | Red LED | Connector | 2.8 ms | |||
 BANNER ENGINEERING | IP67 NEMA 6P | 78.74 " | 2 m | Adjustable Potentiometer | Background Suppression | -20 ░C | 60 °C | 7.874 in | 200 mm | 10 VDC | 30 VDC | NPN - Dark-ON/Light-ON | Red LED | Cable | 2.8 ms | |
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | Through-Beam | -20 ░C | 60 °C | 472.441 " | 12 m | 10 VDC | 30 VDC | Red (655nm) | Connector | 1 ms | |||||
BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | 78.74 " | 2 m | Adjustable Potentiometer | Diffuse | -20 ░C | 60 °C | 4.9 ft | 1.5 m | 10 VDC | 30 VDC | NPN - Dark-ON/Light-ON | Infrared | Cable | 800 µs | 850 nm |
 BANNER ENGINEERING | IEC IEC IP67 IP67 NEMA 6P | 78.74 " | 2 m | Adjustable Potentiometer | Retroreflective NonPolarized | -20 ░C | 60 °C | 236.22 " | 6 m | 10 VDC | 30 VDC | Red (645nm) | Cable | 800 µs | ||
 BANNER ENGINEERING | IP67 NEMA 6P | Adjustable Potentiometer | Background Suppression | -20 ░C | 60 °C | 7.874 in | 200 mm | 10 VDC | 30 VDC | NPN - Dark-ON/Light-ON | Red LED | Connector | 2.8 ms |
