SDM120 Series

Manufacturer: CUI Inc.

Catalog

AC/DC DESKTOP ADAPTER 48V 130W

Part	Standard Number	Operating Temperature [Max]	Cord Length	Cord Length	No Load Power Consumption	Applications	Region Utilized	Voltage - Input [Max]	Voltage - Input [Min]	Efficiency	Power (Watts)	Approval Agency	Polarization	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Voltage - Output	Input Connector	Output Connector	Output Connector [diameter]	Output Connector [x]	Current - Output (Max) [Max]	Input Type	Form	Current - Output (Max)
CUI Inc. SDM120-48-UD-P5	60601-1	40 °C	1.2 m	47.2 in	210 mW	Medical	International	264 VAC	90 VAC	Level VI	130 W	CE cULus FCC TUV	Positive Center	1.34 "	2.32 "	137 mm	34 mm	5.39 "	59 mm	48 V	IEC 320-C8	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	2.7 A	Cord (Sold Separately)	Desktop (Class II)
CUI Inc. SDM120-24-U-P6	60601-1	40 °C	1.2 m	47.2 in	210 mW	Medical	International	264 VAC	90 VAC	Level VI	120 W	CE cULus FCC TUV	Positive Center	1.34 "	2.32 "	137 mm	34 mm	5.39 "	59 mm	24 V	IEC 320-C14	Barrel Plug	2.5 mm 5.5 mm	9.5 mm		Cord (Sold Separately)	Desktop (Class I)	5 A
CUI Inc. SDM120-12-U	60601-1	40 °C	1.2 m	47 in	210 mW	Medical	International	264 VAC	90 VAC	Level VI	110 W	CE cULus FCC TUV		1.34 "	2.32 "	137 mm	34 mm	5.39 "	59 mm	12 V	IEC 320-C14				9.16 A	Cord (Sold Separately)	Desktop (Class I)
CUI Inc. SDM120-24-UD-P5	60601-1	40 °C	1.2 m	47.2 in	210 mW	Medical	International	264 VAC	90 VAC	Level VI	120 W	CE cULus FCC TUV	Positive Center	1.34 "	2.32 "	137 mm	34 mm	5.39 "	59 mm	24 V	IEC 320-C8	Barrel Plug	2.1 mm 5.5 mm	9.5 mm		Cord (Sold Separately)	Desktop (Class II)	5 A
CUI Inc. SDM120-24-UD-P6	60601-1	40 °C	1.2 m	47.2 in	210 mW	Medical	International	264 VAC	90 VAC	Level VI	120 W	CE cULus FCC TUV	Positive Center	1.34 "	2.32 "	137 mm	34 mm	5.39 "	59 mm	24 V	IEC 320-C8	Barrel Plug	2.5 mm 5.5 mm	9.5 mm		Cord (Sold Separately)	Desktop (Class II)	5 A
CUI Inc. SDM120-12-UD-P5	60601-1	40 °C	1.2 m	47.2 in	210 mW	Medical	International	264 VAC	90 VAC	Level VI	110 W	CE cULus FCC TUV	Positive Center	1.34 "	2.32 "	137 mm	34 mm	5.39 "	59 mm	12 V	IEC 320-C8	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	9.16 A	Cord (Sold Separately)	Desktop (Class II)
CUI Inc. SDM120-12-U-P5	60601-1	40 °C	1.2 m	47.2 in	210 mW	Medical	International	264 VAC	90 VAC	Level VI	110 W	CE cULus FCC TUV	Positive Center	1.34 "	2.32 "	137 mm	34 mm	5.39 "	59 mm	12 V	IEC 320-C14	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	9.16 A	Cord (Sold Separately)	Desktop (Class I)
CUI Inc. SDM120-12-U-P6	60601-1	40 °C	1.2 m	47.2 in	210 mW	Medical	International	264 VAC	90 VAC	Level VI	110 W	CE cULus FCC TUV	Positive Center	1.34 "	2.32 "	137 mm	34 mm	5.39 "	59 mm	12 V	IEC 320-C14	Barrel Plug	2.5 mm 5.5 mm	9.5 mm	9.16 A	Cord (Sold Separately)	Desktop (Class I)
CUI Inc. SDM120-19-UD-P5	60601-1	40 °C	1.2 m	47.2 in	210 mW	Medical	International	264 VAC	90 VAC	Level VI	120 W	CE cULus FCC TUV	Positive Center	1.34 "	2.32 "	137 mm	34 mm	5.39 "	59 mm	19 V	IEC 320-C8	Barrel Plug	2.1 mm 5.5 mm	9.5 mm	6.31 A	Cord (Sold Separately)	Desktop (Class II)
CUI Inc. SDM120-12-UD-P6	60601-1	40 °C	1.2 m	47.2 in	210 mW	Medical	International	264 VAC	90 VAC	Level VI	110 W	CE cULus FCC TUV	Positive Center	1.34 "	2.32 "	137 mm	34 mm	5.39 "	59 mm	12 V	IEC 320-C8	Barrel Plug	2.5 mm 5.5 mm	9.5 mm	9.16 A	Cord (Sold Separately)	Desktop (Class II)
