5854/7 Series

Catalog

HOOK-UP WIRE 24AWG 304.8M 1.22MM SILVER COATED COPPER 600VAC SPOOL

Part	Length	Length	Wire Gauge	Qualification	Ratings	Voltage	Cable Type	Operating Temperature [Max]	Operating Temperature [Min]	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Material	Jacket (Insulation) Material	Length [x]	Length [x]	Jacket Color
ALPHA WIRE 5854/7 WH001	1000 ft	304.8 m	24 AWG	MIL-W-16878/4 Type E	UL Style 1213	600 V	Hook-Up	200 °C	-60 °C	32 AWG	7	1.12 mm	0.044 in	0.25 mm	0.01 in	Copper Silver Coated	Polytetrafluoroethylene (PTFE)
ALPHA WIRE 5854/7 BK005			24 AWG	MIL-W-16878/4 Type E	UL Style 1213	600 V	Hook-Up	200 °C	-60 °C	32 AWG	7	1.12 mm	0.044 in	0.25 mm	0.01 in	Copper Silver Coated	Polytetrafluoroethylene (PTFE)	30.5 m	100 ft	Black
ALPHA WIRE 5854/7 OR005			24 AWG	MIL-W-16878/4 Type E	UL Style 1213	600 V	Hook-Up	200 °C	-60 °C	32 AWG	7	1.12 mm	0.044 in	0.25 mm	0.01 in	Copper Silver Coated	Polytetrafluoroethylene (PTFE)	30.5 m	100 ft	Orange
ALPHA WIRE 5854/7-4			24 AWG	MIL-W-16878/4 Type E	UL Style 1213	600 V	Hook-Up	200 °C	-60 °C	32 AWG	7	1.12 mm	0.044 in	0.25 mm	0.01 in	Copper Silver Coated	Polytetrafluoroethylene (PTFE)	30.5 m	100 ft	Green
ALPHA WIRE 5854/7 BL001	1000 ft	304.8 m	24 AWG	MIL-W-16878/4 Type E	UL Style 1213	600 V	Hook-Up	200 °C	-60 °C	32 AWG	7	1.12 mm	0.044 in	0.25 mm	0.01 in	Copper Silver Coated	Polytetrafluoroethylene (PTFE)			Blue
ALPHA WIRE 5854/7 BR001	1000 ft	304.8 m	24 AWG	MIL-W-16878/4 Type E	UL Style 1213	600 V	Hook-Up	200 °C	-60 °C	32 AWG	7	1.12 mm	0.044 in	0.25 mm	0.01 in	Copper Silver Coated	Polytetrafluoroethylene (PTFE)			Brown
ALPHA WIRE 5854/7 SL001	1000 ft	304.8 m	24 AWG	MIL-W-16878/4 Type E	UL Style 1213	600 V	Hook-Up	200 °C	-60 °C	32 AWG	7	1.12 mm	0.044 in	0.25 mm	0.01 in	Copper Silver Coated	Polytetrafluoroethylene (PTFE)			Slate
ALPHA WIRE 5854/7 YL001	1000 ft	304.8 m	24 AWG	MIL-W-16878/4 Type E	UL Style 1213	600 V	Hook-Up	200 °C	-60 °C	32 AWG	7	1.12 mm	0.044 in	0.25 mm	0.01 in	Copper Silver Coated	Polytetrafluoroethylene (PTFE)			Yellow
ALPHA WIRE 5854/7 YL005			24 AWG	MIL-W-16878/4 Type E	UL Style 1213	600 V	Hook-Up	200 °C	-60 °C	32 AWG	7	1.12 mm	0.044 in	0.25 mm	0.01 in	Copper Silver Coated	Polytetrafluoroethylene (PTFE)	30.5 m	100 ft	Yellow
ALPHA WIRE 5854/7 VI005			24 AWG	MIL-W-16878/4 Type E	UL Style 1213	600 V	Hook-Up	200 °C	-60 °C	32 AWG	7	1.12 mm	0.044 in	0.25 mm	0.01 in	Copper Silver Coated	Polytetrafluoroethylene (PTFE)	30.5 m	100 ft	Violet
