CRGS0 Series

Catalog

RES SMD 560 OHM 5% 1/2W 0805

Part	Composition	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Temperature Coefficient	Number of Terminations [custom]	Power (Watts)	Power (Watts)	Features	Supplier Device Package	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Operating Temperature [Max]	Operating Temperature [Min]	Resistance	Package / Case	Package / Case	Size / Dimension [y]
TE Connectivity AMP Connectors CRGS0805J560R	Thick Film	5 %	0.026 in	0.65 mm	100 ppm/°C	2	0.5 W	0.5 W	Pulse Withstanding	0805	2 mm	1.25 mm	0.049 "	0.079 in	155 C	-55 C	560 Ohms	0805
TE Connectivity AMP Connectors CRGS0603J1M8	Thick Film	5 %	0.022 in	0.55 mm	100 ppm/°C	2	0.25 W	0.25 W	Pulse Withstanding		1.6 mm		0.031 in	0.063 "	155 C	-55 C	1.8 MOhms	0603	1608 Metric	0.8 mm
