070984 Series
Manufacturer: Molex
Beta
⌘K
CONN D-SUB PIN 28-36AWG SLDR
| Part | Contact Type | Termination Finish | Contact Material | Contact Finish Thickness | Features | Type | Contact Termination | Contact Form | Wire Gauge [Min] | Wire Gauge [Max] | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Termination Finish Thickness | Termination Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | Male Pin | Tin | Phosphor Bronze | Flash | Matrix Terminal Strip | Signal | Solder | Stamped | 27.5 AWG | 36 AWG | Gold | ||||
Molex | Male Pin | Nickel | Phosphor Bronze | Matrix Terminal Strip | Signal | Solder | Stamped | 27.5 AWG | 36 AWG | Gold | 0.76 Ám | 30 Áin | 50 µin | 1.27 µm | |
 Molex | Male Pin | Tin | Phosphor Bronze | Matrix Terminal Strip | Signal | PCB Solder | Stamped | 27.5 AWG | 36 AWG | Gold | 0.76 Ám | 30 Áin | 100 µin | 2.54 µm | |
Molex | Male Pin | Nickel | Phosphor Bronze | Matrix Terminal Strip | Signal | Solder | Stamped | 27.5 AWG | 36 AWG | Gold | 0.76 Ám | 30 Áin | 50 µin | 1.27 µm | |
Molex | Male Pin | Tin | Phosphor Bronze | Matrix Terminal Strip | Signal | Solder | Stamped | 27.5 AWG | 36 AWG | Gold | 0.76 Ám | 30 Áin | 200 µin | 5.08 µm |
