846-034 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 34POS 0.125
| Part | Material - Insulation | Termination Rows | Pitch | Pitch | Number of Positions/Bay/Row | Flange Feature | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Contact Type | Card Type | Number of Positions [custom] | Mounting Type | Termination | Contact Material | Number of Rows | Gender | Read Out | Color | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows [custom] | Features | Number of Positions/Bay/Row [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 3.18 mm | 0.125 in | 34 | M3 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 34 | Right Angle Through Hole | Solder | Copper Alloy | 1 | Female | Single | Green | 0.25 Ám | 10 Áin | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 3.18 mm | 0.125 in | 34 | Floating Bobbin Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 34 | Through Hole | Wire Wrap | Copper Alloy | 1 | Female | Single | Green | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Flush Mount Top Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Cantilever | Non Specified - Dual Edge | 34 | Board Edge Straddle Mount | Solder Eyelet(s) | Copper Alloy | Female | Dual | Green | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 2 | Card Extender | 17 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Floating Bobbin Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Cantilever | Non Specified - Dual Edge | 34 | Through Hole | Solder Eyelet(s) | Copper Alloy | Female | Dual | Green | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | 2 | 17 | 2 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | 4-40 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Cantilever | Non Specified - Dual Edge | 34 | Right Angle Through Hole | Solder | Copper Alloy | Female | Dual | Green | 0.25 Ám | 10 Áin | 2 | 17 | 2 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | Floating Bobbin Flush Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Cantilever | Non Specified - Dual Edge | 34 | Board Edge Straddle Mount | Solder Eyelet(s) | Copper Alloy | Female | Dual | Green | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | 2 | Card Extender | 17 | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 3.18 mm | 0.125 in | 34 | M3 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 34 | Through Hole | Solder Eyelet(s) | Copper Alloy | 1 | Female | Single | Green | 0.25 Ám | 10 Áin | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Cantilever | Non Specified - Dual Edge | 34 | Through Hole | Solder | Copper Alloy | Female | Dual | Green | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 2 | 17 | 2 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 3.18 mm | 0.125 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Cantilever | Non Specified - Dual Edge | 34 | Board Edge Straddle Mount | Solder Eyelet(s) | Copper Alloy | Female | Dual | Green | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | 2 | Card Extender | 17 | 2 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 3.18 mm | 0.125 in | 34 | Side Mount Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | Gold | Cantilever | Non Specified - Single Edge | 34 | Through Hole | Solder Eyelet(s) | Copper Alloy | 1 | Female | Single | Green | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm |
