BL01RN Series

Catalog

FERRITE BEAD AXIAL RAD BEND 1LN

Part	DC Resistance (DCR) (Max) [Max]	Mounting Type	Current Rating (Max) [Max]	Package / Case	Number of Lines	Size / Dimension [diameter]	Size / Dimension [x]	Size / Dimension [diameter]	Size / Dimension [x]	Operating Temperature [Max]	Operating Temperature [Min]
Murata Electronics BL01RN1A2A2B	20 mOhm	Through Hole	7 A	Axial Radial Bend	1	3.6 mm	5 mm	0.142 in	0.197 in	85 °C	-40 C
Murata Electronics BL01RN1A1F1J		Through Hole	6 A	Axial	1	3.6 mm	5 mm	0.142 in	0.197 in	85 °C	-40 C
Murata Electronics BL01RN1A1D2B	20 mOhm	Through Hole	7 A	Axial	1	3.6 mm	5 mm	0.142 in	0.197 in	85 °C	-40 C
