PPT0020 Series

Catalog

PRESSURE TRANSDUCER

Part	Voltage - Supply [Max]	Voltage - Supply [Min]	Operating Pressure	Operating Pressure	Accuracy	Termination Style	Port Size	Port Size	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Output Type	Pressure Type	Maximum Pressure	Output [Max]	Maximum Pressure [Max]	Maximum Pressure [Max]	Port Style	Port Size	Port Size
Honeywell Aerospace PPT0020GRX5VA	30 VDC	5.5 V	137.9 kPa	20 PSI	0.05 %	Connector	0.125 in 0.13 in	3.18 mm	Module Cube	85 °C	-40 C	Industrial Automation	Analog RS-485	Vented Gauge	60 PSI	5 V
Honeywell Aerospace PPT0020GXW2VB	30 VDC	5.5 V	137.9 kPa	20 PSI	0.05 %	Connector	0.125 in 0.13 in	3.18 mm	Module Cube	85 °C	-40 C	Industrial Automation	Analog RS-232	Vented Gauge		5 V	413.69 kPa	60 PSI
Honeywell Aerospace PPT0020GXF2VB	30 VDC	5.5 V	137.9 kPa	20 PSI	0.05 %	Connector	0.125 in	3.18 mm	Module Cube	85 °C	-40 C	Industrial Automation	Analog RS-232	Vented Gauge		5 V	413.69 kPa	60 PSI	Filtered Threaded	Female Filter
Honeywell Aerospace PPT0020AXN2VB	30 VDC	5.5 V	137.9 kPa	20 PSI	0.05 %	Connector	0.125 in	3.18 mm	Module Cube	85 °C	-40 C	Industrial Automation	Analog RS-232			5 V	413.69 kPa	60 PSI	Threaded	Female Swagelok™
Honeywell Aerospace PPT0020GFF5VA	30 VDC	5.5 V	137.9 kPa	20 PSI	0.05 %	Connector			Module Cube	85 °C	-40 C	Industrial Automation	Analog RS-485	Vented Gauge	60 PSI	5 V			Filtered	Dual Filter
Honeywell Aerospace PPT0020GFW2VA	30 VDC	5.5 V	137.9 kPa	20 PSI	0.05 %	Connector		0.13 in	Module Cube	85 °C	-40 C	Industrial Automation	Analog RS-232	Vented Gauge	60 PSI	5 V			Barbed Filtered	Male Tube Filter	3.18 mm
Honeywell Aerospace PPT0020GFX5VB	30 VDC	5.5 V	137.9 kPa	20 PSI	0.05 %	Connector	0.125 in	3.18 mm	Module Cube	85 °C	-40 C	Industrial Automation	Analog RS-485	Vented Gauge	60 PSI	5 V			Filtered Threaded	Female Filter
Honeywell Aerospace PPT0020GFF2VA	30 VDC	5.5 V	137.9 kPa	20 PSI	0.05 %	Connector			Module Cube	85 °C	-40 C	Industrial Automation	Analog RS-232	Vented Gauge	60 PSI	5 V			Filtered	Dual Filter
Honeywell Aerospace PPT0020GXF5VA	30 VDC	5.5 V	137.9 kPa	20 PSI	0.05 %	Connector	0.125 in	3.18 mm	Module Cube	85 °C	-40 C	Industrial Automation	Analog RS-485	Vented Gauge		5 V	413.69 kPa	60 PSI	Filtered Threaded	Female Filter
Honeywell Aerospace PPT0020ARN5VA	30 VDC	5.5 V	137.9 kPa	20 PSI	0.05 %	Connector	0.13 in	3.18 mm	Module Cube	85 °C	-40 C	Industrial Automation	Analog RS-485			5 V	413.69 kPa	60 PSI	Barbed	Male Tube
