103330 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CONN HEADER R/A 8POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Pitch - Mating	Pitch - Mating	Contact Finish - Post	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Material Flammability Rating	Number of Positions Loaded	Contact Length - Mating	Contact Length - Mating	Style	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Length - Post	Contact Length - Post	Insulation Height [z]	Insulation Height [z]	Insulation Material	Contact Shape	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Type	Number of Rows [custom]	Connector Type	Current Rating (Amps)	Termination	Contact Material	Number of Positions	Insulation Color	Fastening Type	Shrouding	Contact Finish - Mating
TE Connectivity AMP Connectors 9-103330-0-04	2.54 µm	100 µin	0.1 "	2.54 mm	Tin	105 ░C	-65 ░C	Right Angle Through Hole	UL94 V-0	All	0.23 in	5.84 mm	Board to Board Cable	0.1 in	2.54 mm	3.05 mm	0.12 in	0.238 "	6.05 mm	Thermoplastic	Square	100 çin	2.54 çm	Male Pin	2	Header Breakaway	3 A	Solder	Copper Alloy	8	Black	Push-Pull	Unshrouded
TE Connectivity AMP Connectors 4-103330-0-03	2.54 µm	100 µin	0.1 "	2.54 mm	Tin-Lead	105 ░C	-65 ░C	Right Angle Through Hole	UL94 V-0	All	0.23 in	5.84 mm	Board to Board Cable	0.1 in	2.54 mm	3.05 mm	0.12 in	0.238 "	6.05 mm	Thermoplastic	Square	100 çin	2.54 çm	Male Pin	2	Header Breakaway	3 A	Solder	Copper Alloy	6	Black	Push-Pull	Unshrouded	Tin-Lead
TE Connectivity AMP Connectors 9-103330-0-35	2.54 µm	100 µin	0.1 "	2.54 mm	Tin	105 ░C	-65 ░C	Right Angle Through Hole	UL94 V-0	All	0.23 in	5.84 mm	Board to Board Cable	0.1 in	2.54 mm	3.05 mm	0.12 in	0.238 "	6.05 mm	Thermoplastic	Square	100 çin	2.54 çm	Male Pin	2	Header Breakaway	3 A	Solder	Copper Alloy	70	Black	Push-Pull	Unshrouded
TE Connectivity AMP Connectors 103330-5	2.54 µm	100 µin	0.1 "	2.54 mm	Tin-Lead	105 ░C	-65 ░C	Right Angle Through Hole	UL94 V-0	All	0.23 in	5.84 mm	Board to Board Cable	0.1 in	2.54 mm	3.05 mm	0.12 in	0.238 "	6.05 mm	Thermoplastic	Square	100 çin	2.54 çm	Male Pin	2	Header Breakaway	3 A	Solder	Copper Alloy	10	Black	Push-Pull	Unshrouded	Tin-Lead
TE Connectivity AMP Connectors 4-103330-0-04	2.54 µm	100 µin	0.1 "	2.54 mm	Tin-Lead	105 ░C	-65 ░C	Right Angle Through Hole	UL94 V-0	All	0.23 in	5.84 mm	Board to Board Cable	0.1 in	2.54 mm	3.05 mm	0.12 in	0.238 "	6.05 mm	Thermoplastic	Square	100 çin	2.54 çm	Male Pin	2	Header Breakaway	3 A	Solder	Copper Alloy	8	Black	Push-Pull	Unshrouded	Tin-Lead
TE Connectivity AMP Connectors 9-103330-0-36	2.54 µm	100 µin	0.1 "	2.54 mm	Tin	105 ░C	-65 ░C	Right Angle Through Hole	UL94 V-0	All	0.23 in	5.84 mm	Board to Board Cable	0.1 in	2.54 mm	3.05 mm	0.12 in	0.238 "	6.05 mm	Thermoplastic	Square	100 çin	2.54 çm	Male Pin	2	Header Breakaway	3 A	Solder	Copper Alloy	72	Black	Push-Pull	Unshrouded
TE Connectivity AMP Connectors 4-103330-0-15	2.54 µm	100 µin	0.1 "	2.54 mm	Tin-Lead	105 ░C	-65 ░C	Right Angle Through Hole	UL94 V-0	All	0.23 in	5.84 mm	Board to Board Cable	0.1 in	2.54 mm	3.05 mm	0.12 in	0.238 "	6.05 mm	Thermoplastic	Square	100 çin	2.54 çm	Male Pin	2	Header Breakaway	3 A	Solder	Copper Alloy	30	Black	Push-Pull	Unshrouded	Tin-Lead
TE Connectivity AMP Connectors 9-103330-0-19	2.54 µm	100 µin	0.1 "	2.54 mm	Tin	105 ░C	-65 ░C	Right Angle Through Hole	UL94 V-0	All	0.23 in	5.84 mm	Board to Board Cable	0.1 in	2.54 mm	3.05 mm	0.12 in	0.238 "	6.05 mm	Thermoplastic	Square	100 çin	2.54 çm	Male Pin	2	Header Breakaway	3 A	Solder	Copper Alloy	38	Black	Push-Pull	Unshrouded
TE Connectivity AMP Connectors 9-103330-0-15	2.54 µm	100 µin	0.1 "	2.54 mm	Tin	105 ░C	-65 ░C	Right Angle Through Hole	UL94 V-0	All	0.23 in	5.84 mm	Board to Board Cable	0.1 in	2.54 mm	3.05 mm	0.12 in	0.238 "	6.05 mm	Thermoplastic	Square	100 çin	2.54 çm	Male Pin	2	Header Breakaway	3 A	Solder	Copper Alloy	30	Black	Push-Pull	Unshrouded
TE Connectivity AMP Connectors 4-103330-0-10	2.54 µm	100 µin	0.1 "	2.54 mm	Tin-Lead	105 ░C	-65 ░C	Right Angle Through Hole	UL94 V-0	All	0.23 in	5.84 mm	Board to Board Cable	0.1 in	2.54 mm	3.05 mm	0.12 in	0.238 "	6.05 mm	Thermoplastic	Square	100 çin	2.54 çm	Male Pin	2	Header Breakaway	3 A	Solder	Copper Alloy	20	Black	Push-Pull	Unshrouded	Tin-Lead
