896-043 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 43POS 0.125
| Part | Termination Rows | Material - Insulation | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Termination | Mounting Type | Read Out | Number of Positions/Bay/Row | Contact Finish | Card Type | Color | Gender | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Contact Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Through Hole | Single | 43 | Gold | Non Specified - Single Edge | Black | Female | 125 °C | -40 C | 3.18 mm | 0.125 in | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 1 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Through Hole | Single | 43 | Gold | Non Specified - Single Edge | Black | Female | 125 °C | -40 C | 3.18 mm | 0.125 in | 1 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Through Hole | Single | 43 | Gold | Non Specified - Single Edge | Black | Female | 125 °C | -40 C | 3.18 mm | 0.125 in | 0.156 " | 3.96 mm | 1 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Through Hole | Single | 43 | Gold | Non Specified - Single Edge | Black | Female | 125 °C | -40 C | 3.18 mm | 0.125 in | 4-40 Flush Mount Threaded Insert Top Opening | 1 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.25 Ám | 10 Áin | Wire Wrap | Through Hole | Single | 43 | Gold | Non Specified - Single Edge | Black | Female | 125 °C | -40 C | 3.18 mm | 0.125 in | 4-40 Threaded Insert Top Mount Opening | 1 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Through Hole | Single | 43 | Gold | Non Specified - Single Edge | Black | Female | 125 °C | -40 C | 3.18 mm | 0.125 in | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 1 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Through Hole | Single | 43 | Gold | Non Specified - Single Edge | Black | Female | 125 °C | -40 C | 3.18 mm | 0.125 in | 0.128 " | 3.25 mm | 1 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Through Hole | Single | 43 | Gold | Non Specified - Single Edge | Black | Female | 125 °C | -40 C | 3.18 mm | 0.125 in | M3 Threaded Insert Top Mount Opening | 1 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Right Angle Through Hole | Single | 43 | Gold | Non Specified - Single Edge | Black | Female | 125 °C | -40 C | 3.18 mm | 0.125 in | 4-40 Flush Mount Threaded Insert Top Opening | 1 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Copper Alloy | 0.25 Ám | 10 Áin | Solder | Through Hole | Single | 43 | Gold | Non Specified - Single Edge | Black | Female | 125 °C | -40 C | 3.18 mm | 0.125 in | 4-40 Flush Mount Threaded Insert Top Opening | 1 | 43 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever |
