JL04V-6A Series

Catalog

STANDARD CIRCULAR CONNECTOR 22 POS. PLUG

Part	Applications	Ingress Protection	Number of Positions	Features	Shell Size - Insert	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Current Rating (Amps)	Fastening Type	Contact Finish - Mating	Cable Opening	Cable Opening	Orientation	Connector Type	Contact Material	Shell Finish	Shell Material	Color	Primary Material	Voltage Rating	Insert Material	Backshell Material, Plating	Shell Size - Insert [Max]	Shell Size - Insert [Min]	Shell Size - Insert [Min] [custom]	Shell Size - Insert [Max] [custom]
JAE Electronics JL04V-6A28-11SE-R	Industrial Medical Telecommunications Test Equipment & Measurement	IP67 - Dust Tight Waterproof	22	Coupling Nut Ground	28-11	-55 C	125 °C	Free Hanging (In-Line)	13 A 23 A	Threaded	Silver	39.3 mm	1.547 in	N (Normal)	Plug Female Sockets
JAE Electronics JL04V-6A10SL-3SE-R	Industrial Medical Telecommunications Test Equipment & Measurement	IP67 - Dust Tight Waterproof	3	Coupling Nut Ground Lug	10SL-3	-55 C	125 °C	Free Hanging (In-Line)	13 A	Threaded	Silver			N (Normal)	Plug Female Sockets	Copper Alloy	Zinc	Aluminum Alloy	Black	Metal	200 VAC	Synthetic Resin
JAE Electronics JL04V-6A32-17SE-EB-RK	Industrial Medical Telecommunications Test Equipment & Measurement	IP67 - Dust Tight Waterproof	4	Backshell Coupling Nut Ground	32-17	-55 C	125 °C	Free Hanging (In-Line)	80 A	Threaded	Silver			N (Normal)	Plug Female Sockets	Copper Alloy			Black			Synthetic Resin
JAE Electronics JL04V-6A10SL-3SE-EB-R	Industrial Medical Telecommunications Test Equipment & Measurement	IP67 - Dust Tight Waterproof	3	Backshell Coupling Nut Ground Lug	10SL-3	-55 C	125 °C	Free Hanging (In-Line)	13 A	Threaded	Silver			N (Normal)	Plug Female Sockets	Copper Alloy	Zinc	Aluminum Alloy	Black	Metal	200 VAC	Synthetic Resin	Aluminum Alloy Zinc
JAE Electronics JL04V-6A28-11PE-EB-R	Industrial Medical Telecommunications Test Equipment & Measurement	IP67 - Dust Tight Waterproof	22	Backshell Coupling Nut Ground	28-11	-55 C	125 °C	Free Hanging (In-Line)	13 A 23 A	Threaded	Silver			N (Normal)	Plug Male Pins	Copper Alloy	Zinc	Aluminum Alloy	Black	Metal		Synthetic Resin	Aluminum Alloy Zinc
JAE Electronics JL04V-6A24-11PE-EB-R	Industrial Medical Telecommunications Test Equipment & Measurement	IP67 - Dust Tight Waterproof	9	Backshell Coupling Nut Ground Lug	24-11	-55 C	125 °C	Free Hanging (In-Line)	23 A 46 A	Threaded	Silver			N (Normal)	Plug Male Pins	Copper Alloy	Zinc	Aluminum Alloy	Black	Metal		Synthetic Resin	Aluminum Alloy Zinc
JAE Electronics JL04V-6A18-12SE-EB-R	Industrial Medical Telecommunications Test Equipment & Measurement	IP67 - Dust Tight Waterproof	6	Backshell Coupling Nut Ground		-55 C	125 °C	Free Hanging (In-Line)	13 A	Threaded	Silver			N (Normal)	Plug Female Sockets	Copper Alloy	Zinc	Aluminum Alloy	Black	Metal	250 VAC	Synthetic Resin	Aluminum Alloy Zinc	12	18
JAE Electronics JL04V-6A20-18SE-EB-RK	Industrial Medical Telecommunications Test Equipment & Measurement	IP67 - Dust Tight Waterproof	9	Backshell Coupling Nut Ground		-55 C	125 °C	Free Hanging (In-Line)	13 A 23 A	Threaded	Silver			N (Normal)	Plug Female Sockets	Copper Alloy			Black		100 VAC 250 VAC	Synthetic Resin		18	20
JAE Electronics JL04V-6A18-10PE-EB-R	Industrial Medical Telecommunications Test Equipment & Measurement	IP67 - Dust Tight Waterproof	4	Backshell Coupling Nut Ground Lug		-55 C	125 °C	Free Hanging (In-Line)	23 A	Threaded	Silver			N (Normal)	Plug Male Pins	Copper Alloy	Zinc	Aluminum Alloy	Black	Metal		Synthetic Resin	Aluminum Alloy Zinc			18	10
JAE Electronics JL04V-6A32-17SE-EB-R	Industrial Medical Telecommunications Test Equipment & Measurement	IP67 - Dust Tight Waterproof	4	Backshell Coupling Nut Ground	32-17	-55 C	125 °C	Free Hanging (In-Line)	80 A	Threaded	Silver			N (Normal)	Plug Female Sockets	Copper Alloy	Zinc	Aluminum Alloy	Black	Metal		Synthetic Resin	Aluminum Alloy Zinc
