TMB-86 Series
Manufacturer: Floyd Bell Inc
Beta
⌘K
BUZZER PIEZO 33.02MM PNL MNT
| Part | Voltage Range [Min] | Voltage Range [Max] | Approval Agency | Operating Mode | Technology | Mounting Type | Sound Pressure Level (SPL) | Frequency | Current - Supply [Max] | Current - Supply [Min] | Ingress Protection | Termination | Port Location | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Driver Circuitry | Size / Dimension [diameter] | Size / Dimension [diameter] | Input Type | Current - Supply [Max] [x] | Current - Supply [Min] [x] | Termination | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Floyd Bell Inc | 5 VDC | 24 V | UL UR | Fast Pulse | Piezo | Panel Mount | 95 dB | 2.9 kHz | 15 mA | 2 mA | IP68 - Dust Tight Waterproof | Wire Leads | Top | 29.97 mm | 1.18 in | Indicator Internally Driven | 1.3 in | 33.02 mm | |||||
 Floyd Bell Inc | 5 VDC | 30 V | UL UR | Fast Pulse | Piezo | Panel Mount | 95 dB | 2.9 kHz | IP68 - Dust Tight Waterproof | Wire Leads | Top | 29.97 mm | 1.18 in | Indicator Internally Driven | 1.3 in | 33.02 mm | DC | 10 mA | 2 mA | ||||
 Floyd Bell Inc | 30 VDC | 120 V | UL UR | Pulse Slow | Piezo | Panel Mount | 95 dB | 2.9 kHz | 15 mA | 2 mA | IP68 - Dust Tight Waterproof | Quick Connect Tab | Top | 29.97 mm | 1.18 in | Indicator Internally Driven | 1.3 in | 33.02 mm | AC | 0.25 " | 6.35 mm | ||
 Floyd Bell Inc | 9 V | 48 V | UL UR | Fast Pulse | Piezo | Panel Mount | 95 dB | 2.9 kHz | IP68 - Dust Tight Waterproof | Wire Leads | Top | 29.97 mm | 1.18 in | Indicator Internally Driven | 1.3 in | 33.02 mm | DC | 10 mA | 2 mA | ||||
 Floyd Bell Inc | 9 V | 48 V | UL UR | Fast Pulse | Piezo | Panel Mount | 95 dB | 2.9 kHz | IP68 - Dust Tight Waterproof | Quick Connect Tab | Top | 29.97 mm | 1.18 in | Indicator Internally Driven | 1.3 in | 33.02 mm | DC | 10 mA | 2 mA | 0.25 " | 6.35 mm | ||
Floyd Bell Inc | 9 V | 48 V | UL UR | Pulse Slow | Piezo | Panel Mount | 95 dB | 2.9 kHz | IP68 - Dust Tight Waterproof | Wire Leads | Top | 29.97 mm | 1.18 in | Indicator Internally Driven | 1.3 in | 33.02 mm | DC | 10 mA | 2 mA | ||||
Floyd Bell Inc | 5 VDC | 30 V | UL UR | Pulse Slow | Piezo | Panel Mount | 95 dB | 2.9 kHz | IP68 - Dust Tight Waterproof | Quick Connect Tab | Top | 29.97 mm | 1.18 in | Indicator Internally Driven | 1.3 in | 33.02 mm | DC | 10 mA | 2 mA | 0.25 " | 6.35 mm | ||
 Floyd Bell Inc | 9 V | 48 V | UL UR | Pulse Slow | Piezo | Panel Mount | 95 dB | 2.9 kHz | IP68 - Dust Tight Waterproof | Screw Terminal Quick Connect Tab | Top | 29.97 mm | 1.18 in | Indicator Internally Driven | 1.3 in | 33.02 mm | DC | 10 mA | 2 mA | 0.25 " | 6.35 mm | ||
Floyd Bell Inc | 9 V | 48 V | UL UR | Pulse Slow | Piezo | Panel Mount | 95 dB | 2.9 kHz | IP68 - Dust Tight Waterproof | Quick Connect Tab | Top | 29.97 mm | 1.18 in | Indicator Internally Driven | 1.3 in | 33.02 mm | DC | 10 mA | 2 mA | 0.25 " | 6.35 mm | ||
Floyd Bell Inc | 9 V | 48 V | UL UR | Fast Pulse | Piezo | Panel Mount | 95 dB | 2.9 kHz | IP68 - Dust Tight Waterproof | Screw Terminal Quick Connect Tab | Top | 29.97 mm | 1.18 in | Indicator Internally Driven | 1.3 in | 33.02 mm | DC | 10 mA | 2 mA | 0.25 " | 6.35 mm |
