2SA2162 Series

Catalog

TRANS PNP 12V 0.5A SSSMINI3

Part	Frequency - Transition	Voltage - Collector Emitter Breakdown (Max) [Max]	Power - Max [Max]	Supplier Device Package	Operating Temperature	DC Current Gain (hFE) (Min) @ Ic, Vce [Min]	Current - Collector Cutoff (Max) [Max]	Transistor Type	Vce Saturation (Max) @ Ib, Ic	Current - Collector (Ic) (Max) [Max]	Package / Case	Mounting Type
Panasonic Electronic Components 2SA216200L	200 MHz	12 V	100 mW	SSSMini3-F1	125 ¯C	270	100 nA	PNP	250 mV	500 mA	SOT-723	Surface Mount
Panasonic Electronic Components 2SA2162G0L	200 MHz	12 V	100 mW	SSSMini3-F2	125 ¯C	270	100 nA	PNP	250 mV	500 mA	SOT-723	Surface Mount
