CWN-320 Series

Catalog

CONN HEADER R/A 26POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Mounting Type	Number of Positions	Connector Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Type	Shrouding	Material Flammability Rating	Fastening Type	Number of Rows [custom]	Contact Finish - Mating	Number of Positions Loaded	Termination	Contact Material	Insulation Height [z]	Insulation Height [z]	Style	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Length - Mating [x]	Contact Length - Mating [x]	Insulation Color	Pitch - Mating	Pitch - Mating	Insulation Material	Contact Shape	Contact Finish - Post	Contact Length - Post	Contact Length - Post	Operating Temperature [Min]	Operating Temperature [Max]
CW Industries CWN-320-26-0000	1.27 µm	50 µin	Right Angle Through Hole	26	Header	0.25 µm	10 µin	Male Pin	Shrouded - 4 Wall	UL94 V-0	Push-Pull	2	Gold	All	Wire Wrap	Phosphor Bronze	7.4 mm	0.291 in	Board to Cable/Wire	0.1 in	2.54 mm	0.24 in	6.1 mm	Blue	0.1 "	2.54 mm	Thermoplastic	Circular	Nickel	15.49 mm	0.61 in	-55 C	125 °C
CW Industries CWN-320-10-0021	1.27 µm	50 µin	Right Angle Through Hole	10	Header	0.76 Ám	30 Áin	Male Pin	Shrouded - 4 Wall	UL94 V-0	Push-Pull	2	Gold	All	Wire Wrap	Phosphor Bronze	7.4 mm	0.291 in	Board to Cable/Wire	0.1 in	2.54 mm	0.24 in	6.1 mm	Blue	0.1 "	2.54 mm	Thermoplastic	Circular	Nickel	15.49 mm	0.61 in	-55 C	125 °C
CW Industries CWN-320-50-0021	1.27 µm	50 µin	Right Angle Through Hole	50	Header	0.76 Ám	30 Áin	Male Pin	Shrouded - 4 Wall	UL94 V-0	Push-Pull	2	Gold	All	Wire Wrap	Phosphor Bronze	7.4 mm	0.291 in	Board to Cable/Wire	0.1 in	2.54 mm	0.24 in	6.1 mm	Blue	0.1 "	2.54 mm	Thermoplastic	Circular	Nickel	15.49 mm	0.61 in	-55 C	125 °C
CW Industries CWN-320-50-0000	1.27 µm	50 µin	Right Angle Through Hole	50	Header	0.25 µm	10 µin	Male Pin	Shrouded - 4 Wall	UL94 V-0	Push-Pull	2	Gold	All	Wire Wrap	Phosphor Bronze	7.4 mm	0.291 in	Board to Cable/Wire	0.1 in	2.54 mm	0.24 in	6.1 mm	Blue	0.1 "	2.54 mm	Thermoplastic	Circular	Nickel	15.49 mm	0.61 in	-55 C	125 °C
CW Industries CWN-320-20-0000	1.27 µm	50 µin	Right Angle Through Hole	20	Header	0.25 µm	10 µin	Male Pin	Shrouded - 4 Wall	UL94 V-0	Push-Pull	2	Gold	All	Wire Wrap	Phosphor Bronze	7.4 mm	0.291 in	Board to Cable/Wire	0.1 in	2.54 mm	0.24 in	6.1 mm	Blue	0.1 "	2.54 mm	Thermoplastic	Circular	Nickel	15.49 mm	0.61 in	-55 C	125 °C
CW Industries CWN-320-16-0000	1.27 µm	50 µin	Right Angle Through Hole	16	Header	0.25 µm	10 µin	Male Pin	Shrouded - 4 Wall	UL94 V-0	Push-Pull	2	Gold	All	Wire Wrap	Phosphor Bronze	7.4 mm	0.291 in	Board to Cable/Wire	0.1 in	2.54 mm	0.24 in	6.1 mm	Blue	0.1 "	2.54 mm	Thermoplastic	Circular	Nickel	15.49 mm	0.61 in	-55 C	125 °C
CW Industries CWN-320-40-0021	1.27 µm	50 µin	Right Angle Through Hole	40	Header	0.76 Ám	30 Áin	Male Pin	Shrouded - 4 Wall	UL94 V-0	Push-Pull	2	Gold	All	Wire Wrap	Phosphor Bronze	7.4 mm	0.291 in	Board to Cable/Wire	0.1 in	2.54 mm	0.24 in	6.1 mm	Blue	0.1 "	2.54 mm	Thermoplastic	Circular	Nickel	15.49 mm	0.61 in	-55 C	125 °C
CW Industries CWN-320-40-0000	1.27 µm	50 µin	Right Angle Through Hole	40	Header	0.25 µm	10 µin	Male Pin	Shrouded - 4 Wall	UL94 V-0	Push-Pull	2	Gold	All	Wire Wrap	Phosphor Bronze	7.4 mm	0.291 in	Board to Cable/Wire	0.1 in	2.54 mm	0.24 in	6.1 mm	Blue	0.1 "	2.54 mm	Thermoplastic	Circular	Nickel	15.49 mm	0.61 in	-55 C	125 °C
CW Industries CWN-320-14-0000	1.27 µm	50 µin	Right Angle Through Hole	14	Header	0.25 µm	10 µin	Male Pin	Shrouded - 4 Wall	UL94 V-0	Push-Pull	2	Gold	All	Wire Wrap	Phosphor Bronze	7.4 mm	0.291 in	Board to Cable/Wire	0.1 in	2.54 mm	0.24 in	6.1 mm	Blue	0.1 "	2.54 mm	Thermoplastic	Circular	Nickel	15.49 mm	0.61 in	-55 C	125 °C
CW Industries CWN-320-10-0000	1.27 µm	50 µin	Right Angle Through Hole	10	Header	0.25 µm	10 µin	Male Pin	Shrouded - 4 Wall	UL94 V-0	Push-Pull	2	Gold	All	Wire Wrap	Phosphor Bronze	7.4 mm	0.291 in	Board to Cable/Wire	0.1 in	2.54 mm	0.24 in	6.1 mm	Blue	0.1 "	2.54 mm	Thermoplastic	Circular	Nickel	15.49 mm	0.61 in	-55 C	125 °C
