415-13 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN RCPT 54POS 0.1 GOLD PCB

Part	Contact Material	Contact Shape	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Insulation Material	Insulation Height	Insulation Height	Material Flammability Rating	Mounting Type	Contact Finish - Post	Number of Positions	Number of Positions Loaded	Pitch - Mating	Pitch - Mating	Insulation Color	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Finish - Mating	Number of Rows [custom]	Current Rating (Amps)	Contact Type	Fastening Type	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Length - Post	Contact Length - Post	Termination	Insulation Height [z]	Insulation Height [z]	Contact Length - Post	Voltage Rating	Voltage Rating
Mill-Max Manufacturing Corp. 415-13-254-41-003000	Beryllium Copper	Circular	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	1.8 mm	0.071 in	UL94 V-0	Through Hole	Gold	54	All	0.1 "	2.54 mm	Black	0.76 Ám	30 Áin	Receptacle	-55 C	125 °C	Gold	2	3 A	Female Socket	Push-Pull	0.1 in	2.54 mm	2.41 mm	0.095 in	Solder
Mill-Max Manufacturing Corp. 415-13-264-41-004000	Beryllium Copper	Circular	10 Áin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester			UL94 V-0	Through Hole	Gold	64	All	0.1 "	2.54 mm	Black	0.76 Ám	30 Áin	Socket	-55 C	125 °C	Gold	2	3 A	Female Socket	Push-Pull	0.1 in	2.54 mm		2.08 mm	Solder	1.27 mm	0.05 in	0.082 in	100 V	150 VDC
Mill-Max Manufacturing Corp. 415-13-220-41-001000	Beryllium Copper	Circular	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester			UL94 V-0	Through Hole	Gold	20	All	0.1 "	2.54 mm	Black	0.76 Ám	30 Áin	Receptacle	-55 C	125 °C	Gold	2	3 A	Female Socket	Push-Pull	0.1 in	2.54 mm		2.75 mm	Solder			0.108 in
Mill-Max Manufacturing Corp. 415-13-248-41-001000	Beryllium Copper	Circular	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester			UL94 V-0	Through Hole	Gold	48	All	0.1 "	2.54 mm	Black	0.76 Ám	30 Áin	Receptacle	-55 C	125 °C	Gold	2	3 A	Female Socket	Push-Pull	0.1 in	2.54 mm		2.75 mm	Solder			0.108 in
Mill-Max Manufacturing Corp. 415-13-262-41-001000	Beryllium Copper	Circular	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester			UL94 V-0	Through Hole	Gold	62	All	0.1 "	2.54 mm	Black	0.76 Ám	30 Áin	Receptacle	-55 C	125 °C	Gold	2	3 A	Female Socket	Push-Pull	0.1 in	2.54 mm		2.75 mm	Solder			0.108 in
Mill-Max Manufacturing Corp. 415-13-260-41-003000	Beryllium Copper	Circular	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	1.8 mm	0.071 in	UL94 V-0	Through Hole	Gold	60	All	0.1 "	2.54 mm	Black	0.76 Ám	30 Áin	Receptacle	-55 C	125 °C	Gold	2	3 A	Female Socket	Push-Pull	0.1 in	2.54 mm	2.41 mm	0.095 in	Solder
Mill-Max Manufacturing Corp. 415-13-230-41-001000	Beryllium Copper	Circular	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester			UL94 V-0	Through Hole	Gold	30	All	0.1 "	2.54 mm	Black	0.76 Ám	30 Áin	Receptacle	-55 C	125 °C	Gold	2	3 A	Female Socket	Push-Pull	0.1 in	2.54 mm		2.75 mm	Solder			0.108 in
Mill-Max Manufacturing Corp. 415-13-242-41-003000	Beryllium Copper	Circular	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	1.8 mm	0.071 in	UL94 V-0	Through Hole	Gold	42	All	0.1 "	2.54 mm	Black	0.76 Ám	30 Áin	Receptacle	-55 C	125 °C	Gold	2	3 A	Female Socket	Push-Pull	0.1 in	2.54 mm	2.41 mm	0.095 in	Solder
Mill-Max Manufacturing Corp. 415-13-270-41-003000	Beryllium Copper	Circular	10 Áin	0.25 çm	Polycyclohexylenedimethylene Terephthalate (PCT) Polyester	1.8 mm	0.071 in	UL94 V-0	Through Hole	Gold	70	All	0.1 "	2.54 mm	Black	0.76 Ám	30 Áin	Receptacle	-55 C	125 °C	Gold	2	3 A	Female Socket	Push-Pull	0.1 in	2.54 mm	2.41 mm	0.095 in	Solder
Mill-Max Manufacturing Corp. 415-13-236-41-004000	Beryllium Copper	Circular	10 Áin	0.25 çm	Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester			UL94 V-0	Through Hole	Gold	36	All	0.1 "	2.54 mm	Black	0.76 Ám	30 Áin	Socket	-55 C	125 °C	Gold	2	3 A	Female Socket	Push-Pull	0.1 in	2.54 mm		2.08 mm	Solder	1.27 mm	0.05 in	0.082 in	100 V	150 VDC
