LCD3 Series
Manufacturer: Panduit Corp
Beta
⌘K
LUG TERMINAL, LCD SERIES, CRIMP, 000 AWG, COMPRESSION LUG, M10
| Part | Diameter - Ring ID [diameter] | Diameter - Ring ID [diameter] | Terminal Type | Stud/Tab Size | Terminal Style | Tab Thickness | Tab Thickness | Width - Outer Edges [y] | Width - Outer Edges [y] | Mounting Type | Diameter - Barrel ID [diameter] | Diameter - Barrel ID [diameter] | Contact Material | Diameter - Barrel OD [diameter] | Diameter - Barrel OD [diameter] | Termination | Insulation | Contact Finish | Stud/Tab Size | Length - Overall [x] | Length - Overall [x] | Diameter - Ring ID [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panduit Corp | 10.41 mm | 0.41 " | Rectangular Tongue | 3/8 Stud | Two Stud Holes | 0.13 in | 3.3 mm | 24.38 mm | 0.96 in | Free Hanging (In-Line) | 0.51 in | 12.95 mm | Copper | 16.26 mm | 0.64 " | Barrel Crimp | Non-Insulated | Electro-Tin | ||||
 Panduit Corp | 0.34 in | Rectangular Tongue | Two Stud Holes | 0.13 in | 3.3 mm | 24.38 mm | 0.96 in | Free Hanging (In-Line) | 0.51 in | 12.95 mm | Copper | 16.26 mm | 0.64 " | Barrel Crimp | Non-Insulated | Electro-Tin | 0.3125 Stud | 83.06 mm | 3.27 in | 8.64 mm | ||
 Panduit Corp | 0.53 in | Rectangular Tongue | 1/2 Stud | Two Stud Holes | 0.13 in | 3.3 mm | 24.38 mm | 0.96 in | Free Hanging (In-Line) | 0.51 in | 12.95 mm | Copper | 16.26 mm | 0.64 " | Barrel Crimp | Non-Insulated | Electro-Tin | 114 mm | 4.49 in | 13.46 mm | ||
Panduit Corp | 10.41 mm | 0.41 " | Rectangular Tongue | 3/8 Stud | Two Stud Holes | 0.13 in | 3.3 mm | 24.38 mm | 0.96 in | Free Hanging (In-Line) Right Angle | 0.51 in | 12.95 mm | Copper | 16.26 mm | 0.64 " | Barrel Crimp | Non-Insulated | Electro-Tin |
