UP04878 Series

Catalog

MOSFET 2N-CH 50V 0.1A SSMINI6

Part	Technology	Configuration	Vgs(th) (Max) @ Id	Power - Max [Max]	Input Capacitance (Ciss) (Max) @ Vds	Mounting Type	FET Feature	Package / Case	Supplier Device Package	Current - Continuous Drain (Id) @ 25°C	Drain to Source Voltage (Vdss)	Operating Temperature	Rds On (Max) @ Id, Vgs
Panasonic Electronic Components UP0487800L	MOSFET (Metal Oxide)	2 N-Channel (Dual)	1.5 V	125 mW	12 pF	Surface Mount	Logic Level Gate	SOT-563 SOT-666	SSMINI6-F1	100 mA	50 V	125 ¯C	12 Ohm
