8556 Series
Manufacturer: ebm-papst Inc.
Beta
⌘K
FAN AXIAL 76X37MM 230VAC WIRE
| Part | Material - Blade | Lifetime @ Temp. | Material - Frame | Termination | Bearing Type | Operating Temperature [Min] | Operating Temperature [Max] | Approval Agency | RPM | Noise | Voltage - Rated | Width [x] | Weight | Weight | Power (Watts) | Size / Dimension [diameter] | Size / Dimension | Fan Type | Air Flow | Air Flow | Width [y] | Termination | Size / Dimension [z] | Size / Dimension [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | Metal | 52500 Hrs | Metal | 2 Wire Leads | Ball | -40 C | 90 °C | CE CSA UL VDE | 2750 RPM | 26 dB | 230 VAC | 37 mm | 370.13 g | 0.816 lb | 12 W | 76 mm | Round | Tubeaxial | 22.4 CFM | 0.627 m³/min | ||||
 ebm-papst Inc. | Metal | 52500 Hrs | Metal | Ball | -40 C | 90 °C | CE CSA UL VDE | 2800 RPM | 37 dB | 230 VAC | 499 g | 1.1 lbs | 12 W | Tubeaxial | 28.3 CFM | 0.792 m³/min | 38 mm | 2 | 80 mm | 80 mm |
