PSK-S20 Series
Manufacturer: CUI Inc.
Beta
⌘K
AC/DC CONVERTER 15V 20W
| Part | Package / Case | Type | Current - Output (Max) [Max] | Applications | Approval Agency | Mounting Type | Power (Watts) | Load Regulation | Efficiency | Voltage - Output 1 | Voltage - Input [Min] | Voltage - Input [Max] | Standard Number | Line Regulation | Number of Outputs | Features | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Voltage - Isolation | Current - Output 1 | Input Type | AC Voltage - Input [Max] | AC Voltage - Input [Min] | DC Voltage - Input (Min) [Min] | DC Voltage - Input (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CUI Inc. | 4-DIP Module | Enclosed | 1.33 A | ITE (Commercial) | CB Scheme EN IEC UL | Through Hole | 20 W | ±1% | 83 % | 15 V | 85 VAC 100 V | 264 VAC 370 VDC | 55024 55032 Class A 60950-1 61000-3-2 62368-1 | 0.5 % | 1 | Universal Input | 23.5 mm | 53.8 mm | 1.13 " | 0.93 " | 2.12 in | 28.8 mm | |||||||
 CUI Inc. | Enclosed | ITE (Commercial) | CB Scheme EN IEC UL | Chassis Mount | 20 W | 83 % | 24 V | 85 VAC 100 V | 264 VAC 370 VDC | 55024 55032 Class A 60950-1 61000-3-2 62368-1 | 1 | Universal Input | 32.3 mm | 76 mm | 1.24 in | 1.27 " | 2.99 in | 31.5 mm | 4000 V | 833 mA | |||||||||
 CUI Inc. | Enclosed | ITE (Commercial) | CB Scheme EN IEC UL | Chassis Mount | 20 W | 12 V | 85 VAC 100 V | 264 VAC 370 VDC | 55024 55032 Class A 60950-1 61000-3-2 62368-1 | 1 | Universal Input | 32.3 mm | 76 mm | 1.24 in | 1.27 " | 2.99 in | 31.5 mm | 4000 V | 1.66 A | ||||||||||
 CUI Inc. | 3.6 A | ITE (Commercial) | CB Scheme EN IEC UL | 78 % | 5 V | 55024 55032 Class A 60950-1 61000-3-2 62368-1 | 1 | Universal Input | 76 mm | 36.9 mm | 1.24 in | 2.99 in | 1.45 in | 31.5 mm | 4000 V | AC or DC | 264 VAC | 85 VAC | 100 V | 370 V | |||||||||
CUI Inc. | 4-DIP Module | Enclosed | 2.2 A | ITE (Commercial) | CB Scheme EN IEC UL | Through Hole | 20 W | ±1% | 79 % | 9 V | 85 VAC 100 V | 264 VAC 370 VDC | 55024 55032 Class A 60950-1 61000-3-2 62368-1 | 0.5 % | 1 | Universal Input | 23.5 mm | 53.8 mm | 1.13 " | 0.93 " | 2.12 in | 28.8 mm | |||||||
CUI Inc. | 4-DIP Module | Enclosed | 3.6 A | ITE (Commercial) | CB Scheme EN IEC UL | Through Hole | 12 W | ±1% | 74 % | 3.3 V | 85 VAC 100 V | 264 VAC 370 VDC | 55024 55032 Class A 60950-1 61000-3-2 62368-1 | 0.5 % | 1 | Universal Input | 23.5 mm | 53.8 mm | 1.13 " | 0.93 " | 2.12 in | 28.8 mm | |||||||
CUI Inc. | 833 mA | ITE (Commercial) | CB Scheme EN IEC UL | 20 W | 83 % | 24 V | 55024 55032 Class A 60950-1 61000-3-2 62368-1 | 1 | Universal Input | 76 mm | 36.9 mm | 1.24 in | 2.99 in | 1.45 in | 31.5 mm | 4000 V | AC or DC | 264 VAC | 85 VAC | 100 V | 370 V | ||||||||
CUI Inc. | 4-DIP Module | Enclosed | 1.66 A | ITE (Commercial) | CB Scheme EN IEC UL | Through Hole | 20 W | ±1% | 12 V | 85 VAC 100 V | 264 VAC 370 VDC | 55024 55032 Class A 60950-1 61000-3-2 62368-1 | 0.5 % | 1 | Universal Input | 23.5 mm | 53.8 mm | 1.13 " | 0.93 " | 2.12 in | 28.8 mm | ||||||||
CUI Inc. | 1.33 A | ITE (Commercial) | CB Scheme EN IEC UL | 20 W | 83 % | 15 V | 55024 55032 Class A 60950-1 61000-3-2 62368-1 | 1 | Universal Input | 76 mm | 36.9 mm | 1.24 in | 2.99 in | 1.45 in | 31.5 mm | 4000 V | AC or DC | 264 VAC | 85 VAC | 100 V | 370 V | ||||||||
CUI Inc. | Enclosed | ITE (Commercial) | CB Scheme EN IEC UL | Chassis Mount | 12 W | 74 % | 3.3 V | 85 VAC 100 V | 264 VAC 370 VDC | 55024 55032 Class A 60950-1 61000-3-2 62368-1 | 1 | Universal Input | 32.3 mm | 76 mm | 1.24 in | 1.27 " | 2.99 in | 31.5 mm | 4000 V | 3.6 A |
