833-026 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 26POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Color | Termination | Read Out | Contact Type | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Number of Positions | Gender | Flange Feature | Card Thickness [Max] | Card Thickness [Min] | Number of Positions/Bay/Row | Pitch | Pitch | Contact Finish | Number of Rows [custom] | Card Type | Contact Finish Thickness | Contact Finish Thickness | Termination Rows | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | Wire Wrap | Dual | Cantilever | Copper Alloy | 125 °C | -40 C | Through Hole | 26 | Female | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 13 | 3.96 mm | 0.156 in | Gold | 2 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Wire Wrap | Single | Cantilever | Copper Alloy | 125 °C | -40 C | Through Hole | 26 | Female | Floating Bobbin Flush Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 26 | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | 0.116 " | 2.95 mm | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | Solder | Dual | Cantilever | Copper Alloy | 125 °C | -40 C | Through Hole | 26 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 13 | 3.96 mm | 0.156 in | Gold | 2 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Solder | Single | Cantilever | Copper Alloy | 125 °C | -40 C | Through Hole | 26 | Female | Floating Bobbin Flush Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 26 | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | 0.116 " | 2.95 mm | 1 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Wire Wrap | Single | Cantilever | Copper Alloy | 125 °C | -40 C | Through Hole | 26 | Female | M3 Threaded Insert Top Mount Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 26 | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Solder Eyelet(s) | Single | Cantilever | Copper Alloy | 125 °C | -40 C | Through Hole | 26 | Female | Flush Mount M3 Threaded Insert Top Opening | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 26 | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | 1 | |||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | Solder | Dual | Cantilever | Copper Alloy | 125 °C | -40 C | Through Hole | 26 | Female | Side Mount Opening Unthreaded | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 13 | 3.96 mm | 0.156 in | Gold | 2 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | Green | Solder | Single | Cantilever | Copper Alloy | 125 °C | -40 C | Through Hole | 26 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 26 | 3.96 mm | 0.156 in | Gold | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 1 | 0.128 " | 3.25 mm | 1 | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | Solder | Dual | Cantilever | Copper Alloy | 125 °C | -40 C | Through Hole | 26 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 13 | 3.96 mm | 0.156 in | Gold | 2 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 2 | Green | Solder | Dual | Cantilever | Copper Alloy | 125 °C | -40 C | Board Edge Straddle Mount | 26 | Female | Floating Bobbin Flush Mount | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 13 | 3.96 mm | 0.156 in | Gold | 2 | Non Specified - Dual Edge | 0.25 Ám | 10 Áin | 0.116 " | 2.95 mm | Card Extender |
