408-047 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE METAL TO METAL 2 PIECE CONNECTORS ROHS COMPLIANT: YES
| Part | Termination Rows [custom] | Material - Insulation | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Number of Positions | Card Thickness | Card Thickness | Mounting Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Gender | Color | Termination | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Gold | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 47 | 2.36 mm | 0.093 " | Panel Mount Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | Non Specified - Dual Edge | -65 ░C | 125 °C | Female | Green | Solder | 2 | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Gold | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 47 | 1.57 mm | 0.062 in | Panel Mount Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | Non Specified - Dual Edge | -65 ░C | 125 °C | Female | Green | Solder | 2 | Card Guides |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Gold | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 47 | 1.57 mm | 0.062 in | Panel Mount Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | Non Specified - Dual Edge | -65 ░C | 125 °C | Female | Green | Wire Wrap | 2 | Card Guides |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Gold | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 47 | 2.36 mm | 0.093 " | Panel Mount Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | Non Specified - Dual Edge | -65 ░C | 125 °C | Female | Green | Solder | 2 | Card Guides |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Gold | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 47 | 2.36 mm | 0.093 " | Panel Mount Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | Non Specified - Dual Edge | -65 ░C | 125 °C | Female | Green | Solder Eyelet(s) | 2 | Card Guides |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Gold | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 47 | 1.57 mm | 0.062 in | Panel Mount Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | Non Specified - Dual Edge | -65 ░C | 125 °C | Female | Green | Solder | 2 | Card Guides |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Gold | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 47 | 2.36 mm | 0.093 " | Panel Mount Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | Non Specified - Dual Edge | -65 ░C | 125 °C | Female | Green | Solder | 2 | Card Guides |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Gold | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 47 | 1.57 mm | 0.062 in | Panel Mount Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | Non Specified - Dual Edge | -65 ░C | 125 °C | Female | Green | Solder Eyelet(s) | 2 | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Gold | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 47 | 2.36 mm | 0.093 " | Panel Mount Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | Non Specified - Dual Edge | -65 ░C | 125 °C | Female | Green | Solder | 2 | Card Guides |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Gold | 0.25 Ám | 10 Áin | 5.08 mm | 0.2 in | 47 | 2.36 mm | 0.093 " | Panel Mount Through Hole | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Copper Alloy | Non Specified - Dual Edge | -65 ░C | 125 °C | Female | Green | Solder | 2 |
