392-056 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 56POS 0.100
| Part | Termination Rows | Material - Insulation | Card Type | Contact Material | Pitch | Pitch | Read Out | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Mounting Type | Contact Finish | Number of Positions | Color | Gender | Number of Positions/Bay/Row | Number of Rows | Termination | Operating Temperature [Min] | Operating Temperature [Max] | Termination Rows [custom] | Features | Number of Rows [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Copper Alloy | 0.1 " | 2.54 mm | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Gold | 56 | Black | Female | 56 | 1 | Solder | -40 C | 105 ░C | ||||||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | Copper Alloy | 0.1 " | 2.54 mm | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Board Edge Straddle Mount | Gold | 56 | Black | Female | 28 | Solder Eyelet(s) | -40 C | 105 ░C | 2 | Card Extender | 2 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | ||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | Copper Alloy | 0.1 " | 2.54 mm | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Right Angle Through Hole | Gold | 56 | Black | Female | 28 | Solder Wire Wrap | -40 C | 105 ░C | 2 | 2 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Copper Alloy | 0.1 " | 2.54 mm | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Gold | 56 | Black | Female | 56 | 1 | Wire Wrap | -40 C | 105 ░C | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Copper Alloy | 0.1 " | 2.54 mm | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Gold | 56 | Black | Female | 56 | 1 | Solder | -40 C | 105 ░C | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Non Specified - Single Edge | Copper Alloy | 0.1 " | 2.54 mm | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Gold | 56 | Black | Female | 56 | 1 | Solder | -40 C | 105 ░C | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | Copper Alloy | 0.1 " | 2.54 mm | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Board Edge Straddle Mount | Gold | 56 | Black | Female | 28 | Solder | -40 C | 105 ░C | 2 | Card Extender | 2 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | ||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | Copper Alloy | 0.1 " | 2.54 mm | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Right Angle Through Hole | Gold | 56 | Black | Female | 28 | Solder Wire Wrap | -40 C | 105 ░C | 2 | 2 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | Copper Alloy | 0.1 " | 2.54 mm | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Gold | 56 | Black | Female | 28 | Wire Wrap | -40 C | 105 ░C | 2 | 2 | ||||||
 EDAC Inc. | Polyester Thermoplastic | Non Specified - Dual Edge | Copper Alloy | 0.1 " | 2.54 mm | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Cantilever | Through Hole | Gold | 56 | Black | Female | 28 | Solder | -40 C | 105 ░C | 2 | 2 |
