E2B-S08 Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
SENSOR PROX INDUCTIVE 1MM CYLIND
| Part | Material - Body | Termination Style | Response Frequency | Voltage - Supply [Min] | Voltage - Supply [Max] | Sensing Distance | Sensing Distance | Indicator | Shielding | Operating Temperature [Min] | Operating Temperature [Max] | Package / Case | Sensor Type | Output Type | Ingress Protection | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | Stainless Steel | Cable Leads | 2 kHz | 10 VDC | 30 VDC | 1 mm | 0.039 " | LED | Shielded | -25 °C | 70 °C | Cylinder Threaded - M8 | Inductive | 3-Wire NPN-NO | IP67 | |
Omron Automation and Safety | Stainless Steel | Cable Leads | 2 kHz | 10 VDC | 30 VDC | 1 mm | 0.039 " | LED | Shielded | -25 °C | 70 °C | Cylinder Threaded - M8 | Inductive | 3-Wire NPN-NO | IP67 | |
Omron Automation and Safety | Stainless Steel | Cable Leads | 2 kHz | 10 VDC | 30 VDC | 1 mm | 0.039 " | LED | Shielded | -25 °C | 70 °C | Cylinder Threaded - M8 | Inductive | 3-Wire NPN-NC | IP67 | |
 Omron Automation and Safety | Stainless Steel | Cable Leads | 1 kHz | 10 VDC | 30 VDC | 4 mm | 0.157 in | LED | Unshielded | -25 °C | 70 °C | Cylinder Threaded - M8 | Inductive | PNP-NC | IP67 | 3 |
 Omron Automation and Safety | Stainless Steel | Wire Leads | 1.5 kHz | 10 VDC | 30 VDC | 2 mm | 0.079 in | LED | Shielded | -25 °C | 70 °C | Cylinder Threaded - M8 | Inductive | PNP-NC | IP67 | 3 |
 Omron Automation and Safety | Stainless Steel | Connector | 1.5 kHz | 10 VDC | 30 VDC | 2 mm | 0.079 in | LED | Shielded | -25 °C | 70 °C | Cylinder Threaded - M8 | Inductive | 3-Wire NPN-NC | IP67 | |
Omron Automation and Safety | Stainless Steel | Cable Leads | 1 kHz | 10 VDC | 30 VDC | 2 mm | 0.079 in | LED | Unshielded | -25 °C | 70 °C | Cylinder Threaded - M8 | Inductive | PNP-NO | IP67 | 3 |
Omron Automation and Safety | Stainless Steel | Connector | 1 kHz | 10 VDC | 30 VDC | 2 mm | 0.079 in | LED | Unshielded | -25 °C | 70 °C | Cylinder Threaded - M8 | Inductive | 3-Wire NPN-NO | IP67 | |
Omron Automation and Safety | Stainless Steel | Cable Leads | 1 kHz | 10 VDC | 30 VDC | 2 mm | 0.079 in | LED | Unshielded | -25 °C | 70 °C | Cylinder Threaded - M8 | Inductive | PNP-NO | IP67 | 3 |
Omron Automation and Safety | Stainless Steel | Wire Leads | 1.5 kHz | 10 VDC | 30 VDC | 2 mm | 0.079 in | LED | Shielded | -25 °C | 70 °C | Cylinder Threaded - M8 | Inductive | 3-Wire NPN-NO | IP67 |
