039535 Series

Manufacturer: Molex

Catalog

Catalog

TERM BLOCK HDR 9POS VERT 5.08MM

...

Part	Contact Material	Mounting Type	Termination Style	Pitch [x]	Pitch [x]	Contact Mating Finish	Features	Type	Operating Temperature [Min]	Operating Temperature [Max]	Number of Positions	Number of Levels	Contact Tail Length	Contact Tail Length	Voltage - UL	Insulation Height	Insulation Height	Header Orientation	Material Flammability Rating	Positions Per Level	Color	Housing Material
Molex 0395350509	Brass	Through Hole	Solder	0.2 in	5.08 mm	Gold	Mating Flange	Header Male Pins Shrouded (4 Side)	-40 °C	115 °C	9	1	0.15 in	3.81 mm	300 V	0.472 in	12 mm	Vertical	UL94 V-0	9	Black
Molex 0395350006	Brass	Through Hole	Solder	0.2 in	5.08 mm	Tin	Mating Flange	Header Male Pins Shrouded (4 Side)	-40 °C	115 °C	6	1	0.15 in	3.81 mm	300 V	0.472 in	12 mm	Vertical	UL94 V-0	6	Black
Molex 0395350524	Brass	Through Hole	Solder	0.2 in	5.08 mm	Gold	Mating Flange	Header Male Pins Shrouded (4 Side)	-40 °C	115 °C	24	1	0.15 in	3.81 mm	300 V	0.472 in	12 mm	Vertical	UL94 V-0		Black
Molex 0395355504	Brass	Through Hole	Solder	0.2 in	5.08 mm	Gold	Mating Flange	Header Male Pins Shrouded (4 Side)	-40 °C	115 °C	4	1	0.15 in	3.81 mm	300 V	0.472 in	12 mm	Vertical	UL94 V-0	4	Green
Molex 0395350508	Brass	Through Hole	Solder	0.2 in	5.08 mm	Gold	Mating Flange	Header Male Pins Shrouded (4 Side)	-40 °C	115 °C	8	1	0.15 in	3.81 mm	300 V	0.472 in	12 mm	Vertical	UL94 V-0	8	Black
Molex 0395354004	Brass	Through Hole	Solder	0.2 in	5.08 mm	Tin	Mating Flange	Header Male Pins Shrouded (4 Side)	-40 °C	105 ░C	4	1	0.15 in	3.81 mm	300 V	0.472 in	12 mm	Vertical	UL94 V-0	4	Black	Polyamide (PA46) Nylon 4/6
Molex 0395350502	Brass	Through Hole	Solder	0.2 in	5.08 mm	Gold	Mating Flange	Header Male Pins Shrouded (4 Side)	-40 °C	115 °C	2	1	0.15 in	3.81 mm	300 V	0.472 in	12 mm	Vertical	UL94 V-0	2	Black
Molex 0395354521	Brass	Through Hole	Solder	0.2 in	5.08 mm	Gold	Mating Flange	Header Male Pins Shrouded (4 Side)	-40 °C	105 ░C	21	1	0.15 in	3.81 mm	300 V	0.472 in	12 mm	Vertical	UL94 V-0	21	Black	Polyamide (PA46) Nylon 4/6
Molex 0395355520	Brass	Through Hole	Solder	0.2 in	5.08 mm	Gold	Mating Flange	Header Male Pins Shrouded (4 Side)	-40 °C	115 °C	20	1	0.15 in	3.81 mm	300 V	0.472 in	12 mm	Vertical	UL94 V-0	20	Green
Molex 0395350019	Brass	Through Hole	Solder	0.2 in	5.08 mm	Tin	Mating Flange	Header Male Pins Shrouded (4 Side)	-40 °C	115 °C	19	1	0.15 in	3.81 mm	300 V	0.472 in	12 mm	Vertical	UL94 V-0	19	Black
