Small and high Brightness RGB LED
Description
AI
This product is a 6pin type product. MSL04 series is a small reflector type side-emitting RGB chip LED. The small size enables matrix display by integration.
Beta
⌘K
Small and high Brightness RGB LED
Small and high Brightness RGB LED
| Part | Color | Lens Style | Package / Case | Wavelength - Dominant [custom] | Wavelength - Dominant [custom] | Wavelength - Dominant [custom] | Size / Dimension [x] | Size / Dimension [y] | Mounting Type | Lens Transparency | Millicandela Rating [custom] | Millicandela Rating [custom] | Millicandela Rating [custom] | Configuration | Height (Max) [z] | Current - Test | Lens Color | Supplier Device Package | Supplier Device Package | Lens Size [y] | Lens Size [x] | Voltage - Forward (Vf) (Typ) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | Blue Green Red | Rectangle with Flat Top | 6-SMD No Lead | 470 nm | 624 nm | 527 nm | 1.8 mm | 1.6 mm | Surface Mount | Diffused | 550 mcd | 400 mcd | 180 mcd | Independent | 0.6 mm | 20mA Blue 20mA Green 20mA Red | White | 1816 | 0706 | 1.6 mm | 1.8 mm | 2.1 V 3.3 V 3.5 V |
