109L1724 Series

Catalog

FAN AXIAL 172X51MM 24VDC WIRE

Part	Material - Frame	Material - Blade	Lifetime @ Temp.	Current Rating (Amps)	Operating Temperature [Min]	Operating Temperature [Max]	Approval Agency	Noise	Size / Dimension [diameter]	Size / Dimension	Voltage - Rated	Power (Watts)	Static Pressure	Static Pressure	Termination	Weight [custom]	Weight [custom]	Fan Type	Features	Bearing Type	Width [x]	Air Flow	Air Flow	RPM
Sanyo Denki America Inc. 109L1724H5D01	Aluminum	Plastic	100000 Hrs	580 mA	-20 ░C	70 °C	CSA TUV UL	47 dB	172 mm	Round	24 VDC	13.92 W	0.551 in H2O	137.2 Pa	3 Wire Leads	780 g	1.7 lbs	Tubeaxial	Locked Rotor Sensor	Ball	51 mm	6.33 m³/min	226 CFM
Sanyo Denki America Inc. 109L1724M501	Aluminum	Plastic	100000 Hrs	0.2 A	-20 ░C	70 °C	CSA TUV UL	36 dB	172 mm	Round	24 VDC	4.8 W	0.271 in H2O	67.6 Pa	3 Wire Leads	780 g	1.7 lbs	Tubeaxial	Speed Sensor (Tach)	Ball	51 mm	4.14 mł/min	148 CFM	2000 RPM
Sanyo Denki America Inc. 109L1724H501	Aluminum	Plastic	100000 Hrs	580 mA	-20 ░C	70 °C	CSA TUV UL	47 dB	172 mm	Round	24 VDC	13.92 W	0.551 in H2O	137.2 Pa	3 Wire Leads	780 g	1.7 lbs	Tubeaxial	Speed Sensor (Tach)	Ball	51 mm	6.33 m³/min	226 CFM
Sanyo Denki America Inc. 109L1724M502	Aluminum	Plastic	100000 Hrs	0.2 A	-20 ░C	70 °C	CSA TUV UL	36 dB	172 mm	Round	24 VDC	4.8 W	0.271 in H2O	67.6 Pa	2 Wire Leads	780 g	1.7 lbs	Tubeaxial		Ball	51 mm	4.14 mł/min	148 CFM	2000 RPM
