837-029 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 29POS 0.156
| Part | Termination Rows | Material - Insulation | Color | Number of Positions/Bay/Row | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Gender | Number of Rows | Contact Type | Termination | Read Out | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Number of Positions | Flange Feature | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 29 | Gold | 0.25 Ám | 10 Áin | Female | 1 | Cantilever | Wire Wrap | Single | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 29 | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 29 | Gold | 0.25 Ám | 10 Áin | Female | 1 | Cantilever | Solder | Single | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 29 | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.25 mm | 0.128 " |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 29 | Gold | 0.25 Ám | 10 Áin | Female | 1 | Cantilever | Wire Wrap | Single | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 29 | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 29 | Gold | 0.25 Ám | 10 Áin | Female | 1 | Cantilever | Wire Wrap | Single | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 29 | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 29 | Gold | 0.25 Ám | 10 Áin | Female | 1 | Cantilever | Solder | Single | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 29 | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 3.96 mm | 0.156 " |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 29 | Gold | 0.25 Ám | 10 Áin | Female | 1 | Cantilever | Wire Wrap | Single | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 29 | Floating Bobbin Flush Mount | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 2.95 mm | 0.116 " |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 29 | Gold | 0.25 Ám | 10 Áin | Female | 1 | Cantilever | Solder | Single | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 29 | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 29 | Gold | 0.25 Ám | 10 Áin | Female | 1 | Cantilever | Solder Eyelet(s) | Single | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 29 | M3 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 29 | Gold | 0.25 Ám | 10 Áin | Female | 1 | Cantilever | Solder | Single | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 29 | 4-40 Threaded Insert Top Mount Opening | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Green | 29 | Gold | 0.25 Ám | 10 Áin | Female | 1 | Cantilever | Solder | Single | Copper Alloy | 125 °C | -40 C | Non Specified - Single Edge | 29 | Side Mount Opening Unthreaded | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 3.25 mm | 0.128 " |
