16_MMCX-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
16_MMCX-50-1-7/111_OH
| Part | Voltage Rating | Dielectric Material | Center Contact Plating | Body Material | Mating Cycles | Operating Temperature [Max] | Operating Temperature [Min] | Body Finish | Impedance | Connector Style | Number of Ports | Cable Group | Contact Termination | Fastening Type | Connector Type | Frequency - Max [Max] | Housing Color | Shield Termination | Center Contact Material | Mounting Type | Cable Group |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | 170 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | 500 | 155 C | -55 C | Gold | 50 Ohms | MMCX | 1 | RG-178 | Solder | Snap-On | Plug Male Pin | 6000 MHz | Gold | Crimp | Beryllium Copper | Free Hanging (In-Line) Right Angle | |
 Huber+Suhner, Inc. | 170 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | 500 | 155 C | -55 C | Gold | 50 Ohms | MMCX | 1 | RG-178 | Solder | Snap-On | Plug Male Pin | 6000 MHz | Gold | Crimp | Bronze | Free Hanging (In-Line) Right Angle | 196 |
Huber+Suhner, Inc. | 170 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | 500 | 155 C | -55 C | Gold | 50 Ohms | MMCX | 1 | RG-178 | Solder | Snap-On | Plug Male Pin | 6000 MHz | Gold | Crimp | Beryllium Copper | Free Hanging (In-Line) Right Angle | |
 Huber+Suhner, Inc. | 170 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | 500 | 155 C | -55 C | Gold | 50 Ohms | MMCX | 1 | 188 316 RG-174 | Solder | Snap-On | Plug Male Pin | 6000 MHz | Gold | Crimp | Beryllium Copper | Free Hanging (In-Line) Right Angle | |
 Huber+Suhner, Inc. | 170 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | 500 | 155 C | -55 C | Gold | 50 Ohms | MMCX | 1 | RD-316 | Solder | Snap-On | Plug Male Pin | 6000 MHz | Gold | Crimp | Beryllium Copper | Free Hanging (In-Line) Right Angle | |
 Huber+Suhner, Inc. | 170 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | 500 | 155 C | -55 C | Gold | 50 Ohms | MMCX | 1 | 188 316 RG-174 | Solder | Snap-On | Plug Male Pin | 6000 MHz | Gold | Crimp | Beryllium Copper | Free Hanging (In-Line) Right Angle | |
Huber+Suhner, Inc. | 170 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | 500 | 155 C | -55 C | Gold | 50 Ohms | MMCX | 1 | RG-405 (.086 Semi Rigid) | Solder | Snap-On | Plug Male Pin | 6000 MHz | Gold | Solder | Bronze | Free Hanging (In-Line) Right Angle | |
 Huber+Suhner, Inc. | 170 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | 500 | 155 C | -55 C | Gold | 50 Ohms | MMCX | 1 | Crimp | Snap-On | Plug Male Pin | 6000 MHz | Gold | Solder | Beryllium Copper | Free Hanging (In-Line) Right Angle | ||
 Huber+Suhner, Inc. | 170 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | 500 | 155 C | -55 C | Gold | 50 Ohms | MMCX | 1 | RG-405 (.086 Semi Rigid) | Solder | Snap-On | Plug Male Pin | 6000 MHz | Gold | Solder | Brass | Free Hanging (In-Line) Right Angle | |
 Huber+Suhner, Inc. | 170 V | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | Gold | Brass | 500 | 155 C | -55 C | Gold | 50 Ohms | MMCX | 1 | Solder | Snap-On | Plug Male Pin | 6000 MHz | Gold | Solder | Beryllium Copper | Free Hanging (In-Line) Right Angle | 0.047 in |
