M80-4000000FD Series
Manufacturer: Harwin Inc.
Beta
⌘K
CONN DATAMATE FEM 2POS
| Part | Contact Material | Applications | Contact Shape | Insulation Material | Insulation Height | Insulation Height | Insulation Color | Number of Rows | Features | Connector Type | Voltage Rating | Contact Length - Post | Contact Length - Post | Contact Type | Mounting Type | Termination | Current Rating (Amps) | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions Loaded | Material Flammability Rating | Number of Positions | Pitch - Mating | Pitch - Mating | Style | Mated Stacking Heights | Contact Finish - Mating | Contact Length - Post [x] | Contact Length - Post [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Harwin Inc. | Copper Alloy | General Purpose | Circular | Polyphenylene Sulfide (PPS) Glass Filled | 5.2 mm | 0.205 " | Black | 1 | Jackscrews Polarizing Key | Receptacle | 800 V | 0.138 in | 3.5 mm | Female Socket Power | Through Hole | Solder | 20 A | -55 C | 125 °C | All | UL94 V-0 | 2 | 4 mm | 0.157 in | Board to Board Cable | 7.3 mm | Gold | ||
Harwin Inc. | Copper Alloy | General Purpose | Circular | Polyphenylene Sulfide (PPS) Glass Filled | 5.2 mm | 0.205 " | Black | 1 | Jackscrews Polarizing Key | Receptacle | 800 V | 0.138 in | 3.5 mm | Female Socket Power | Through Hole | Solder | 20 A | -55 C | 125 °C | All | UL94 V-0 | 12 | 4 mm | 0.157 in | Board to Board Cable | 7.3 mm | Gold | ||
Harwin Inc. | Copper Alloy | General Purpose | Circular | Polyphenylene Sulfide (PPS) Glass Filled | 5.2 mm | 0.205 " | Black | 1 | Jackscrews Polarizing Key | Receptacle | 800 V | Female Socket Power | Through Hole | Solder | 40 A | -55 C | 150 °C | All | UL94 V-0 | 5 | 4 mm | 0.157 in | Board to Board Cable | 7.3 mm | Gold | 0.197 " | 5 mm | ||
Harwin Inc. | Copper Alloy | General Purpose | Circular | Polyphenylene Sulfide (PPS) Glass Filled | 5.2 mm | 0.205 " | Black | 1 | Jackscrews Polarizing Key | Receptacle | 0.118 in | 3 mm | Through Hole | Solder | -55 C | 125 °C | All | UL94 V-0 | 5 | 4 mm | 0.157 in | Board to Board Cable | 7.3 mm | Gold | |||||
Harwin Inc. | Copper Alloy | General Purpose | Circular | Polyphenylene Sulfide (PPS) Glass Filled | 5.2 mm | 0.205 " | Black | 1 | Jackscrews Polarizing Key | Receptacle | 800 V | Female Socket Power | Through Hole | Solder | 20 A | -55 C | 125 °C | All | UL94 V-0 | 2 | 4 mm | 0.157 in | Board to Board Cable | 7.3 mm | Gold | 0.197 " | 5 mm | ||
Harwin Inc. | Copper Alloy | General Purpose | Circular | Polyphenylene Sulfide (PPS) Glass Filled | 5.2 mm | 0.205 " | Black | 1 | Jackscrews Polarizing Key | Receptacle | 0.118 in | 3 mm | Through Hole | Solder | -55 C | 125 °C | All | UL94 V-0 | 4 | 4 mm | 0.157 in | Board to Board Cable | 7.3 mm | Gold | |||||
Harwin Inc. | Copper Alloy | General Purpose | Circular | Polyphenylene Sulfide (PPS) Glass Filled | 5.2 mm | 0.205 " | Black | 1 | Jackscrews Polarizing Key | Receptacle | 800 V | Female Socket Power | Through Hole | Solder | 20 A | -55 C | 125 °C | All | UL94 V-0 | 4 mm | 0.157 in | Board to Board Cable | 7.3 mm | Gold | 0.197 " | 5 mm | |||
Harwin Inc. | Copper Alloy | General Purpose | Circular | Polyphenylene Sulfide (PPS) Glass Filled | 5.2 mm | 0.205 " | Black | 1 | Jackscrews Polarizing Key | Receptacle | 800 V | 0.138 in | 3.5 mm | Female Socket Power | Through Hole | Solder | 40 A | -55 C | 150 °C | All | UL94 V-0 | 6 | 4 mm | 0.157 in | Board to Board Cable | 7.3 mm | Gold | ||
 Harwin Inc. | Copper Alloy | General Purpose | Circular | Polyphenylene Sulfide (PPS) Glass Filled | 5.2 mm | 0.205 " | Black | 1 | Jackscrews Polarizing Key | Receptacle | 800 V | 0.138 in | 3.5 mm | Female Socket Power | Through Hole | Solder | 20 A | -55 C | 125 °C | All | UL94 V-0 | 6 | 4 mm | 0.157 in | Board to Board Cable | 7.3 mm | Gold |
