845-023 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 23POS 0.100
| Part | Termination Rows | Material - Insulation | Card Type | Number of Positions/Bay/Row | Operating Temperature [Max] | Operating Temperature [Min] | Read Out | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Material | Termination | Number of Positions | Number of Rows | Contact Type | Color | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Gender | Pitch | Pitch |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 23 | 125 °C | -40 C | Single | Through Hole | 0.25 Ám | 10 Áin | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Copper Alloy | Wire Wrap | 23 | 1 | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 23 | 125 °C | -40 C | Single | Through Hole | 0.25 Ám | 10 Áin | Copper Alloy | Solder | 23 | 1 | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.1 " | 2.54 mm | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 23 | 125 °C | -40 C | Single | Right Angle Through Hole | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | Copper Alloy | Solder | 23 | 1 | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.1 " | 2.54 mm | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 23 | 125 °C | -40 C | Single | Through Hole | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | Copper Alloy | Wire Wrap | 23 | 1 | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.1 " | 2.54 mm | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 23 | 125 °C | -40 C | Single | Through Hole | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Copper Alloy | Wire Wrap | 23 | 1 | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 23 | 125 °C | -40 C | Single | Through Hole | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Solder | 23 | 1 | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.1 " | 2.54 mm | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 23 | 125 °C | -40 C | Single | Through Hole | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | Copper Alloy | Solder | 23 | 1 | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.1 " | 2.54 mm | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 23 | 125 °C | -40 C | Single | Through Hole | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Copper Alloy | Wire Wrap | 23 | 1 | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.1 " | 2.54 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 23 | 125 °C | -40 C | Single | Through Hole | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | Copper Alloy | Solder | 23 | 1 | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.1 " | 2.54 mm | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Non Specified - Single Edge | 23 | 125 °C | -40 C | Single | Through Hole | 0.25 Ám | 10 Áin | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Solder | 23 | 1 | Cantilever | Green | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 0.1 " | 2.54 mm |
