LAP-301 Series

Catalog

DISPLAY 7SEG 0.31" SGL GRN 10DIP

Part	Common Pin	Color	Number of Characters	Display Type	Power Dissipation (Max) [Max]	Millicandela Rating	Package / Case	Package / Case	Package / Case	Voltage - Forward (Vf) (Typ)	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Current - Test	Wavelength - Peak [custom]	Digit/Alpha Size	Digit/Alpha Size	Wavelength - Peak
Rohm Semiconductor LAP-301ML	Common Cathode	Green	1	7-Segment	448 mW	100 mcd	5.3 mm	10-DIP	0.209 in	1.9 V	5 mm	0.276 in	11 mm	7 mm	0.433 in	0.197 "	10 mA	572 nm	0.31 in	8 mm
Rohm Semiconductor LAP-301VB	Common Anode	Red	1	7-Segment	448 mW	36 mcd	5.3 mm	10-DIP	0.209 in	1.9 V	5 mm	0.276 in	11 mm	7 mm	0.433 in	0.197 "	10 mA		0.31 in	8 mm	650 nm
Rohm Semiconductor LAP-301YL	Common Cathode	Yellow	1	7-Segment	448 mW	450 mcd	5.3 mm	10-DIP	0.209 in	1.9 V	5 mm	0.276 in	11 mm	7 mm	0.433 in	0.197 "	10 mA		0.31 in	8 mm	590 nm
Rohm Semiconductor LAP-301YB	Common Anode	Yellow	1	7-Segment	448 mW	450 mcd	5.3 mm	10-DIP	0.209 in	1.9 V	5 mm	0.276 in	11 mm	7 mm	0.433 in	0.197 "	10 mA		0.31 in	8 mm	590 nm
